JIANLIAN HOMECARE PRODUCTS CO., LIMITED

JL110A ELECTRIC WHEELCHAIR MANUAL

1. Product Introduction

JL110A (see Illustration 1), is the intelligent folding electric wheelchair, the operation is flexible and easy

to use. The frame material is made of high strength aluminum alloy, light and firm. Many human and

practical designs can help the users of the operation to realize their own life.

Accessories: Charger 1 pc

Foldable

backrest

Controller

PU rear wheel

Battery

PU castor

Motor

Illustration 1

Soft cushion

Flip up armrest

Detachable

footrest

Table of Contents

Need help?

Do you have a question about the JL110A and is the answer not in the manual?

Questions and answers

Summary of Contents for HOMECARE PRODUCTS JL110A

Page 1 JL110A ELECTRIC WHEELCHAIR MANUAL 1. Product Introduction JL110A (see Illustration 1), is the intelligent folding electric wheelchair, the operation is flexible and easy to use. The frame material is made of high strength aluminum alloy, light and firm. Many human and practical designs can help the users of the operation to realize their own life.
Page 2 JIANLIAN HOMECARE PRODUCTS CO., LIMITED 2. Product Specification Outer Dimension (cm): 117×63×96 Folding Dimension (cm): 80×35×77 Seat width (cm): 46 Seat depth (cm): 44 Backrest height (cm): 44 Seat height (cm):53 Castor diameter (cm): 20 Driving wheel diameter (cm): 32 Net Weight: 51 kg (incl.
Page 3 JIANLIAN HOMECARE PRODUCTS CO., LIMITED 1). Connect the controller with the battery. 2). Release the clutch as following position (In the case of insufficient power, the switch can be released to push the wheelchair).
Page 4 JIANLIAN HOMECARE PRODUCTS CO., LIMITED 3). Switch on the power switch on the controller. It means the power is enough when all the light is on. Adjust the speed to the minimum (The speed can be faster when skilled in using) and hold the handle to...
Page 5 JIANLIAN HOMECARE PRODUCTS CO., LIMITED 4.) The driving speed can be adjusted by the knob (+) or (-) on the controller. It means the wheelchair has reached the maximum speed when all speed light is on. 5.) It means the power is enough when all the power volume lights on. It means the power is exhausted when there is only red light on, please stop using and charge immediately.
Page 6 JIANLIAN HOMECARE PRODUCTS CO., LIMITED 4). Clean the wheelchair frequently with neutral detergents, wipe off water immediately if there is any to keep wheelchair dry. 5). Always clean the wheel axis (clean up wool, hair, etc), check whether the screws are loose and adjust them properly.
