Cytech UCM/4G Quick Start Manual

UCM/4G
This is the UCM/4G Quick Start Guide. Please download the full UCM/4G
Manual from http://www.cytech.biz/ucmgsm_manual.html
The UCM/4G provides a 4G (LTE) cellular network connection to Comfort. This
gives Comfort the following abilities;
Acts as a backup for alarm dialout when the land line is faulty or cut. Alternately,
•
it can be used as the primary dialler without a fixed telephone line, for
installations where a telephone line is not available.
Allows the user to dial to the GSM number instead of the fixed telephone line to
•
access Comfort menus.
Allows Comfort to report alarms to the users mobile phones via SMS. The SMS
•
message will show time stamp, Text Identification, Alarm type and Zone or User
name.
Allows authorised Mobile phones to send commands to control or check the
•
status of appliances and the security system via SMS. Each Phone can be
independently authorised to arm, disarm, and access automation control.
Allows date and time update by Internet Time servers
•
The UCM/4G requires a Nano SIM card to be inserted, just like with a cellular
phone. This can be a prepaid card, or one which is billed monthly according to a
usage plan.
Features of UCM/4G
Zone and Alarm Names (32 characters) are stored in UCM/4G EEPROM.
•
64 Customised messages can be sent by SMS
•
Help Messages are sent by SMS
•
Query Security Mode and Control Status
•
Home Control SMS Command will reply with Status
•
Arm/Disarm Security System will reply with Security Mode status.
•
Alarm SMS messages from Comfort include Time Stamp
•
Alarm SMS messages from Comfort includes User Names instead of Number for
•
user alarms e.g. Arm and disarm
Each Phone has Permissions for SMS Arm, SMS Disarm, SMS Control
•
Support for non-English character sets using UCS2 (future upgrade)
•
Specifications
UCM/4G
PCB Size: 108 x 88 mm
•
Power Supply (from Comfort): 12V 50 ma (idle), 250 ma (transmit)
•
Operating Temperature: 0-55°C
•
Frequency Bands: GSM (2G): 900/1800 Mhz, WCDMA (3G) : B1 (2100 Mhz),
•
B5(850 Mhz) B8 (900 Mhz) , LTE (4G): FDD-B1 (2100 Mhz), FDD-B3 (1800
Mhz), FDD-B5 (850 Mhz), FDD-B7 (2600 Mhz), FDD-B8 (900 Mhz), FDD-B20
(800 Mhz), TDD-B38 (2600 Mhz), TDD-B40 (2300 Mhz), TDD-B41 (2500 Mhz)
SIM Card Interface : 3V/1.8V
•
Operating Temperature Range: 0 to 60 deg C
•
