IMPORTANT
Carefully remove all the parts from the carton and place them
individually on a soft cloth to prevent scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
This product is made of aluminum. Do not use power tools
above 8 volts to assemble and only tighten bolts until snug.
Over tightening can damage the aluminum.
Part List
Hardware List
Hex Wrench
1 pc.
Hex Wrench (short)
1 pc.
home
6658-83
Chaise
A.
Seat
1 pc.
E.
Support
1 pc.
F.
Axle
1 pc.
M8x30
Head Cap Bolt
4 pcs. (+1 extra)
M8x60
Head Cap Bolt (long)
2 pcs. (+1 extra)
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
B.
C.
Arm
Arm
1 pc.
1 pc.
G.
Wheel
2 pcs.
Spring Washer
10 pcs. (+1 extra)
M8x25
Head Cap Bolt (short)
4 pcs. (+1 extra)
D.
Back Frame
1 pc.
H.
Cushion
1 pc.
Flat Washer
10 pcs. (+1 extra)
M6x15
Short Bolt
2 pcs. (+1 extra)
888-680-7460
Plastic Washer
2 pcs. (+1 extra)
Cap
2 pcs. (+1 extra)
Advertisement
Related Manuals for Homestyles 6658-83
Summary of Contents for Homestyles 6658-83
- Page 1 6658-83 Chaise IMPORTANT Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage. Carefully and strictly follow these assembly instructions to ensure a completed product as designed. This product is made of aluminum. Do not use power tools above 8 volts to assemble and only tighten bolts until snug.
- Page 2 Assembly Instructions 2/5 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ The unit must be level to work properly.
- Page 3 Assembly Instructions 3/5 Flat Washer Spring Washer Head Cap Bolt (long) Head Cap Bolt Spring Washer Flat Washer Plastic Washer STEP 2 Attach Back Frame (D) to unit with Plastic Washer, Flat Washer, Spring Washer and Head Cap Bolt (long), tightening bolt only halfway.
- Page 4 Assembly Instructions 4/5 Large Hole Head Cap Bolt (short) Spring Washer Flat Washer Short Bolt Large Hole Head Cap Bolt (short) Spring Washer Flat Washer STEP 3 Attach Support (E) to unit with Flat Washers, Spring Washers and Head Cap Bolts (short), tightening bolts only halfway.
- Page 5 Assembly Instructions 5/5 STEP 4 Turn unit over to its upright position. Level unit by adjusting the adjustable levelers on bottom of unit. (See Figure 6) Place Cushion (H) onto unit. Figure 6 STEP 5 Attach Cushion (H) to unit with velcro. (See Figure 7) Velcro Figure 7...
- Page 6 CARE INSTRUCTIONS NEVER NEVER use glass cleaners on allow liquids to remain on furniture. finished furniture. Ammonia Absorption causes parts to warp chemically attacks the finish. and split and finishes to delaminate. Do not use power tools Do not place Do not write above 8 volts to assemble.
