- Page 1 INSTALLATION INSTRUCTIONS 3036A030 Tieback Mount Rev Jun-2021...
-
Page 2: Table Of Contents
Wallenstein backhoes are designed to work with a wide variety Safety ................3 of skid steers. This tieback mount provides a method to attach Safety Alert Symbol ............3 and detach a Wallenstein backhoe to a New Holland® L223 skid Signal Words ..............3 steer. Safety Information............3 Tieback Mounts ............4... -
Page 3: Safety
Safety 3036A030 Tieback Mount Safety Safety Alert Symbol This Safety Alert Symbol means: ATTENTION! BE ALERT! YOUR SAFETY IS INVOLVED! The Safety Alert Symbol identifies important safety messages on the machine and in this instruction. This symbol means be alert to the possibility of personal injury or death. Follow instructions provided. -
Page 4: Tieback Mounts
Tieback Mounts 3036A030 Tieback Mount Tieback Mounts Install the two tieback mounts on the skid steer. Tieback Mount Parts Fig. 1 – Tieback Mount Parts Item Part Description Quantity Number Z771715 Hex bolt, M12 x 1.75 x 55 mm Not included... -
Page 5: Tools Required
Tieback Mounts 3036A030 Tieback Mount Tools Required • Basic shop tools. • One socket wrench with a 19 mm socket. • One calibrated torque wrench with a 19 mm socket. Install the Tieback Mount Tieback mount item numbers are in brackets and defined under Tieback Mount Parts on page 4. - Page 6 Tieback Mounts 3036A030 Tieback Mount Step 3 Use a calibrated torque wrench to tighten the two hex bolts and two lock nuts to the specified torque (only the RH side is shown). For torque specifications, see Common Bolt Torque Values on...
-
Page 7: Connect A Quick-Attach Plate
Tieback Mounts 3036A030 Tieback Mount Connect a Quick-Attach Plate The backhoe must have an SQ500 universal quick-attach plate installed (not included). For instructions, see SQ500 Universal Quick-Attach Plate on page 9. Quick-attach plate item numbers are in brackets and defined under SQ500 Universal Quick-Attach Plate Parts on page 9. - Page 8 Tieback Mounts 3036A030 Tieback Mount Step 3 Align and secure the quick-attach plate. Turn the toplinks to tighten or loosen them, as required.
-
Page 9: Sq500 Universal Quick-Attach Plate
SQ500 Universal Quick-Attach Plate An SQ500 universal quick-attach plate is not included with the tieback mount. If you have questions or would like more information, contact your local dealer, the distributor, or Wallenstein Equipment. SQ500 Universal Quick-Attach Plate Parts 01673 Fig. -
Page 10: Install A Quick-Attach Plate On A Backhoe
SQ500 Universal Quick-Attach Plate 3036A030 Tieback Mount Install a Quick-Attach Plate on a Backhoe Step 1 IMPORTANT! Stabilize the backhoe to prevent movement Align the pivot-backhoe weldment (12) with the backhoe main during installation. frame (for information about the location of backhoe parts, see the backhoe Operator's Manual). -
Page 11: Install The Toplink Assemblies
SQ500 Universal Quick-Attach Plate 3036A030 Tieback Mount Install the Toplink Assemblies Quick-attach plate item numbers are in brackets and defined under SQ500 Universal Quick-Attach Plate Parts on page 9. Tools Required • Basic shop tools. • One calibrated torque wrench with 7/8" socket. - Page 12 SQ500 Universal Quick-Attach Plate 3036A030 Tieback Mount Step 3 Complete the following for each turnbuckle clevis (only the LH side is shown): a. Align the toplink (5) with a turnbuckle clevis. b. Insert a hitch pin (7) through the toplink and turnbuckle- clevis holes.
-
Page 13: Adjust The Quick-Attach Plate Position
SQ500 Universal Quick-Attach Plate 3036A030 Tieback Mount Adjust the Quick-Attach Plate Position Quick-attach plate item numbers are in brackets and defined under SQ500 Universal Quick-Attach Plate Parts on page 9. Tools Required • Basic shop tools. • One calibrated torque wrench with 1 1/4"... - Page 14 SQ500 Universal Quick-Attach Plate 3036A030 Tieback Mount Step 3 Rotate the pivot-backhoe weldment to adjust the backhoe angle. Align the holes in the required position. 01679 Step 4 Complete the following on each side of the pivot-backhoe weldment (LH and RH side): a.
-
Page 15: Common Bolt Torque Values
Common Bolt Torque Values 3036A030 Tieback Mount Common Bolt Torque Values Checking Bolt Torque Imperial Bolt Torque Specifi cations The tables shown give correct torque values for various Torque Value bolts and capscrews. Tighten all bolts to the torque Bolt values specified in the table, unless indicated otherwise. - Page 16 www.wallensteinequipment.com...
