Roxy RSA-65M Operation Manual

SPECIFICATIONS
Model No. RSA-65M / RSA-60DP
POWER REQUIREMENT AC: 220-240V 50/60Hz,
DC: 12V Car Battery
R.M.S POWER OUTPUT:
MAXIMUM 80 Watts
At 10% THD 65 Watts
At 5% THD 45 Watts
At 2% THD 36 Watts
INPUT CHANNELS 4 x Mic 0.5mV/ 4.7K? ,
2-AUX:
AUX-1 50mV/ 470K? ,
AUX-2 150mV/ 250K?
DIGITAL PLAYER* MP3 Player with USB/ BT/ FM Functions & Remote Control
FREQUENCY RESPONSE 60Hz - 15000Hz ± 3dB
TONE CONTROLS BASS: ±10dB at 100Hz (Cut-Boost Type)
TREBLE: ±10dB at 10KHz (Cut-Boost Type)
LINE BOOSTER OUTPUT 500mV/ 600?
S/N RATIO 60dB
OUTPUT TAPS FOR SPEAKERS 4? , 8? , 16? & 100V Line
PROTECTION 2A AC Fuse, AMPLIFIER IS PROTECTED
AGAINST WRONG BATTERY POLARITY
DIMENSIONS W385 x 120H x 295D mm
WEIGHT 6.250 KG
* Not available in RSA-65M
MADE IN INDIA
• Design and Specifications are subject to change without notice.
• Technical specifications are estimates only 12/18.
www.roxy.in
www.roxy.in
OPERATION OPERATION
M A N U A L M A N U A L
PA Mixer Amplifier + Digital Player
65W RMS / 80W Max.
USB
READER
MODEL No.
RSA-65M
