DEMO MANUAL DC2258A

parts List

ITEM QTY
Required Circuit Components
1 1
2 1
3 1
4 1
8 1
9 1
10 1
11 1
12 1
Additional Demo Board Circuit Components
4 1
Hardware: For Demo Board Only
5 4
6 1
7 1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C1 CAP., 4.7µF, X7R, 50V, 10%, 1206
C2 CAP., 4.7µF, X7R, 25V, 10%, 0805
C3 CAP., 1000pF, C0G, 25V, 5%, 0603
C4 CAP., 1µF, X7R, 25V, 10%, 0603
L1 IND., 22µH, PWR, WE-LQS, 20%
R1 RES., 1MΩ, 1%, 1/10W, 0603
R2 RES., 66.5kΩ, 1%, 1/10W, 0603
U1 I.C., DFN-2×2, 8-LEAD
PCB, DC2258A
C5 CAP., 1µF, X7R, 25V, 10%, 0603
E1, E2, E3, E4 TEST POINT, TURRET, .094", THT
JP1 CONN., HEADER, 1×3, 2mm
XJP1 SHUNT, 2mm
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475KA12L
TDK, C2012X7R1E475K125AB
MURATA, GRM1885C1E102JA01D
TDK, C1608X7R1E105K080AB
WURTH ELEKTRONIK, 74404024220
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060366K5FKEA
LINEAR TECH., LT3048EDC#PBF
DEMO CIRCUIT 2258A
TDK, C1608X7R1E105K080AB
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
