Owner's Manual
Thank you very much for choosing a dotRed product.
We hope that this unit will bring you countless hours of fun.
Keep this owner's manual handy for future reference.
The latest version of this manual is available for free
download (PDF) on our website.
© 2016 dotRed Audio Designs Co., Ltd.
Rev. E01
Advertisement
Table of Contents
Summary of Contents for dotRed Audio Designs WORKFRAME 84
- Page 1 We hope that this unit will bring you countless hours of fun. Keep this owner’s manual handy for future reference. The latest version of this manual is available for free download (PDF) on our website. © 2016 dotRed Audio Designs Co., Ltd. Rev. E01...
-
Page 2: Included Items
Make sure that the package contains the main unit and all the included items listed below. Owner’s Manual (this document) Owner’s Manual © 2016 dotRed Audio Designs Co., Ltd. Rev. Exx AC adaptor AC adaptor cord M3 x 8-type screws ... -
Page 3: Precautions For Use
PRECAUTIONS FOR USE CAUTION ！ Use this product by following all safety precautions in this owner's manual. This product has a circuit protection feature intended to protect the unit in case of overvoltage and short-circuit under normal conditions of use as described in this manual. However, due to several factors, we cannot guarantee that this feature will effectively protect the unit in all cases. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Heed all precautions for your own safety! WARNING ！ Keep this unit as well as its AC adaptor away from rain and any damp/wet environment. If any liquid get splashed onto or gets inside this unit or its AC adaptor, this can cause a malfunction and poses a risk of electric shock. - Page 5 NAME & FUNCTION OF EACH COMPONENT Ｂ Ｂ Ｂ ３ Ａ Ｃ Ｄ Ｅ Ｆ Ｇ Ｂ Ｂ ４ ５ Ａ Logo plate: Ｄ DC15V input: Ｇ Headers: This plate can be removed if you need to fit Connect the AC adaptor's DC cable These fourteen 16-pin headers deliver one more module, and can also be moved to end plug here.
- Page 6 MODULE INSTALLATION １． Insert a square nut into the rail via ４． Slightly tighten both screws so as one of its nut holes. to be able to slide the module in place onto the mounting rails. ２． Using the tip of a pen, slide the ５．...
- Page 7 FEATURES ◆Ideal-size case for new Eurorackers or users wishing to expand their existing system. ◆Rugged full-metal chassis offering effective protection from noise and shocks. ◆30-watt power module optimized for 84HP case size and power needs. The power module's design prevents power line noise while ensuring lower heat under full-load condition.
-
Page 8: Specifications
SPECIFICATIONS ◆Case format: Euro-rack (Doepfer's A-100 format), 84HP ◆Power Specs AC adaptor ・AC input ：100V～240V AC / 50～60Hz ・DC output：15V / 3.34A （2.5A min.） ・DC plug type: Outside Φ: 5.5mm Inside Φ: 2.1mm Polarity: center + "POWER BASE" power module ・DC input: 15V (less than 18V) ・DC output current: 1000mA@+12V... -
Page 9: Optional Parts
OPTIONAL PARTS (available separately) ◆"RACK-EAR" Brackets (pair) for 19-inch rack mount ◆"NUTS'n BOLTS" Screws and Square nuts for module installation M3 x 8 screws: 30pcs Square nuts: 30pcs... -
Page 10: Before Using This Unit
BEFORE USING THIS UNIT ●Before using this unit, install your modules refering to the "MODULE INSTALLATION" section in this manual. ●To install our optional rack-mount ears on this unit, refer to the owner's manual supplied with the dotRed rack-ear brackets. ENVIRONMENT OF USE &... -
Page 11: Year Limited Warranty
A listing of our authorized distributors is available at http://www.dotred-audio-designs.com/shops DOTRED AUDIO DESIGNS warrants to the first owner of a covered product purchased from an authorized DOTRED AUDIO DESIGNS dealer in the U.S., that this product will be free from defects in materials and/or workmanship for a period of one year from the date of purchase. -
Page 12: Troubleshooting
TROUBLESHOOTING If this unit does not seem to work properly and shows some of the symptoms described here below, make sure each installed module works correctly before sending the unit in for repair. Symptoms - When powering on the unit, the status indicators do not light up. - When powering on the unit, the status indicators’... -
Page 13: Warranty Card
WARRANTY CARD dotRed Audio Designs Co., Ltd. 9-10, Kamijima, Hamakita-ku, Hamamatsu 434-0011 JAPAN Model：WORKFRAME 84 Address: Customer Name: Shop or seller’s signature: Warranty term: Purchase date: 1 year ◆Keep this warranty card together with your receipt or sales slip as a proof of the purchase location and date will be requestedfor any warranty claim.
