The BLExtender is a Bluetooth range extender, designed to allow you to use your BMPRO SmartConnect and Switch
devices from every corner of your RV without worrying about losing Bluetooth signal.
Pairing Button
Power Connector
Mounting the BLExtender
The BLExtender should be mounted in a central location
between the sensors and the node. It is mounted using four
#8 screws at the mounting points.
Powering the BLExtender
Power the BLExtender using a maximum 14GA wire from a
12V power source.
System Compatibility
The BLExtender is compatible with BMPRO's
JAYCOMMAND/TravelLINK system. Your firmware or app
may need to be updated prior to pairing. Check your user
manual for details on how to update your firmware and app.
Pairing the BLExtender to the Node with a Controller
To use the BLExtender, it must be paired to the Node.
To pair the BLExtender to your system if it has a Controller:
1. Once mounted and powered using the included
connector, press the pair button.
2. Using the < or > buttons on the Controller, navigate to
the PA menu item.
3. When 'PA' appears on the display, press the EXT button
to start the pairing process to the Node. 'PA' will blink
for a maximum of 30 seconds or until the BLExtender is
connected.
If the BLExtender is not paired and connected within 30 seconds, you will need to press the pairing button again.
The LED will flash different colors during the pairing process, refer to the LED status table for more information.
Once the BLExtender is paired, it will begin extending the Bluetooth range of all SmartConnect sensors and any Switch
connected to the Node!
TEAM
19 Henderson Rd, Knoxfield, VIC 3180 Australia
BMPRO
Unit 1, 821 E Windsor Ave, Elkhart IN 46514 USA
.COM
service@teambmpro.com
BLExtender
Adjustable Antenna
STATE
Initialization
Pairing
Paired and connected
Forgetting node
Re-connecting with a
paired node
Pairing with unsupported
firmware
LED Status Table
LED STATUS
Flashing white and yellow
Flashing blue
Flashing green
Flashes white twice
Flashing red and blue
Flashing red
Manual Part 036297
Rev 1.0
Advertisement
Table of Contents
Summary of Contents for BMPRO BLExtender
- Page 1 If the BLExtender is not paired and connected within 30 seconds, you will need to press the pairing button again. The LED will flash different colors during the pairing process, refer to the LED status table for more information.
- Page 2 NODE! Unpairing the BLExtender from the NODE To unpair the BLExtender, press and hold the pairing button for 7 seconds. The LED will blink white during this process, and will turn off once it has been unpaired.
