Installation Guidelines
The 144 Port MAQS System has three connection types:
•
DSL - RJ21/Champ connector to DSLAM
•
Distribution/Line - signal to customer's premise
•
Feeder/POTS - signal to CO
To reduce the risk of fire, use only No. 26 AWG or thicker
gauge telecommunication line cord/cable.
Installation - Attach Ground. There two locations available
Ground
Attach DSL cables
Maintain wire twist.
For Assistance
techhelp@comtestnetworks.com
Copyright © 2020, Comtest Networks Inc.
Pin 1
1-877-369-5499
www.comtestnetworks.com
144 Port MAQS System
Installation Guide
Ground
Advertisement
Table of Contents
Summary of Contents for Comtest Networks SA-7010-2101
- Page 1 Feeder/POTS - signal to CO To reduce the risk of fire, use only No. 26 AWG or thicker gauge telecommunication line cord/cable. Maintain wire twist. Copyright © 2020, Comtest Networks Inc. Installation - Attach Ground. There two locations available Ground Ground...
- Page 2 150 Port RLS Panel Installation Guide Attach Feeder/POTS cables Grey Shroud Attach Distribution/Line cables Grey Shroud Grey Shroud For Assistance 1-877-369-5499 techhelp@comtestnetworks.com www.comtestnetworks.com...
- Page 3 150 Port RLS Panel Installation Guide Port Numbering Block 1 Block 2 Block 3 Block 4 Block 5 Block 6 RJ21 Pin Out RJ21 PINOUT Port Signal Port Signal Port Signal Signal RING RING RING RING RING RING RING RING RING RING RING...
