- Page 1 EZ PANEL SUKKAH • 1 •...
-
Page 2: Panel Assembly
PANEL ASSEMBLY All panels (and corner sections on some models) work on a Male/ Female assembly system. Using two Male sides or two Female sides, will not interlock. Please ensure the white caps are on the top side of the panel, & the light wood color side, is on the inside of the sukkah (dark outside). - Page 3 CORNER ASSEMBLY First layout the sukkah panels the way you would like to set it up. Position panels at a 45° angle, then hook male side of panel (1), into the connector female front side of panel (2) (to the female left of it), then swing in the direction of arrow shown in diagram to create...
- Page 4 HOW TO CONNECT THE SIDE PANELS Place panels side by side, position the 2 panels at a 135° angle, then insert male (R) side of panel (1) into female female side (L) of panel (2), (as shown in diagram). Swing panels into place.
- Page 5 THE ORDER IN WHICH TO CONNECT THE PANELS Please note doors & windows are interchangeable with a standard panel of the same size. • 4 •...
- Page 6 HOW TO CONNECT THE LAST PANEL 1. After completing diagram (10) connect the last panel in the middle on one side. 2. Push the 2 edges of the last 2 panels outwards, connect the male/female connection, 3. After ensuring the interlock is properly connected from top to bottom, pull back in to the straight position.
- Page 7 PANEL CONNECTOR INSTALLATION After each panel to panel connection is made, use the connector (see to help keeps the panels together. Connectors should be placed diagram) on the top of the panels, where the 2 panels connect. Use the corners connector over each corner, to keep the corners straight.
- Page 8 HOW TO ATTACH THE HANDLES In the center of the door there are two holes for the purpose of attaching the handles. There are two holes on the left side and two holes on the right side. The holes are closed by plastic plugs. Please take out the plugs from the holes on the side you wish to open (the side you opened the hinges) You must screw on the handles from both sides of the door...
- Page 9 SUKKAH WOOD SIZE CHART In order to strengthen the walls of the Sukkah, place wood inside the panel connectors around the top perimeter of the Sukkah, see size chart below. If you are able to cut the wood, it is best to place the wood from corner to corner.
