Alpha Digital T101 Quick Start Manual

T101 Portable Power Supply Quick Start Guide
a
Using with DC 12V Devices
Connect the DC appliance to the power supply's 5.5mm 12V DC port,
press the " " button to switch on DC output. Long press the "
for 3 seconds to switch off.
Note: The power supply will automatically turn off after 30 seconds if it
does not detect a connected device.
c
Using with USB Devices
Connect the USB cable to one of the T101 power supply's USB
sockets. Connect the other end to your USB device.
Press the " " button to turn on USB output. Long press the button for
3 seconds to switch off.
Note: The power supply will automatically turn off after 30 seconds if it
does not detect a connected device.
USB C
How To Use The Power Supply
" button
b
Using with AC Devices
Connect the AC appliance to one of the T101 power supply's AC outlet.
Long press "AC" button for 3 seconds to switch on the power button and the
unit will start providing power to your appliances. Long press the button for
3 seconds to switch off.
d
Using the LED Flashlight
1. Turn on
Double press " " button to switch on the LED lamp.
2. Change light modes
LED Lamp
Double press " " button to switch between modes Flashlight / Blink / SOS.
2. To turn off
Long press " " button 3 seconds to switch off the LED lamp.
