Audacy AH-CO2THD Product Manual

Product Manual
AH-CO2THD Temperature Sensor

PRODUCT DESCRIPTION

The Audacy AH-CO2THD is a battery
powered device specially designed to detect
the CO2/temperature/humidity
wirelessly transmit this information to the
Audacy Gateway. The information provided
by the sensor is used to determine if HVAC
systems should be adjusted to achieve the
desired environmental conditions. The
product has a 25-year battery life design and
will not require AC or DC line power,
providing building owners and occupant
placement flexibility.
KEY FEATURES
FCC and IC approved
Flexible ceiling mounting options
25+ year battery life
Small form factor with internal antenna
RoHS compliant
Factory configurable for custom
applications
Audacy®, Smart Connector® and Smart Switch® are registered trademarks of IDEAL INDUSTRIES.
ND7946-1 01/2014 Users Manual – AH-CO2THD Temperature Humidity Sensor
and
All other trademarks are the property of their respective owners.
Page 1
www.idealindustries.com
PRODUCT CONTENTS
The following items are included inside the
package:
Qty Description
1 Temperature Sensor AH-CO2THD
1 Sensor Cradle
2 Mounting Screw
1 Locking Screw
1 Instruction card
