CS-422B Bluetooth Gamepad Manual
Big Motor
1、INTRODUCTION：
This gamepad is P4 BT Wireless Controller 3rd Edition, suitable for PS4 console,
compatible with PS4 Bluetooth wireless specification. Corresponding to 4 analog
axes, 2 analog buttons and 16 digital keys, 2-Points Touch Pad, RGB Light Bar, Big
and Small Vibration, 6-axis Motion Sensor, Mono Speaker, Headset Jack, and
supports PC under wired connection, Wireless pairing function.
2、PRODUCT DESCRIPTION：
2.1 Support Bluetooth wireless connection（Bluetooth 4.2+EDR Specification)。
2.2 Support USB wired pairing（USB 1.1 or USB 2.0,Micro B)
2.3 Button&Stick (Digital button*16, analog button*2, analog axis 4, analog resolution is 256
steps）
Button Digital/Analog
PS
OPTION
SHARE
L3
R3
Circle
Cross
USB (Micro B) & Light Bar
Speaker
Headset Jack
Button
D Up
D Down
D L1
D L2
R1
D
D R2
D Touch Key
Small Motor
Digital/Analog
D
D
D
D/A(0 to 255)
D
D/A(0 to 255)
D
