- Page 1 MP-321 Marine Diesel Engine Operation manual Overcourt, School Lane, MICKLEHAM, Surrey, RH5 6EW, UK Email: info@marine-power-solutions.com Tel: +44 (0)1202 618236...
-
Page 2: Table Of Contents
Contents 1. Foreword 2. General information 3. Engine component guide 4. Running Instructions 4.1 Starting the engine 4.2 Running instructions 4.3 Shutdown procedure Checks and service 5.1 Check daily before starting 5.2 Check every 14 days 5.3 Service every 50 hours of operation 5.4 Service every 100 hours of operation 6 Laying-up and launching 7 Fault Tracing Scheme... -
Page 3: Foreword
1. Foreword 1.1 Introduction This introduction book provides helpful information for running and maintaining your marine diesel engine. The contents apply to particular engines specifications. Each engine is supplied from Marine Power Solutions is in accordance with the published specifications. Examine your engine and other components to be able to find them in this book. -
Page 4: General Information
2. General information Important information concerning the function to your engine 2.1 Fuel Users can select the proper grade of fuel according to the local ambient temperature as follows: ASTM D975No.1-D No.2-D……for USA EN590:96………………………..for EU ISO8217DMX……………………international BS2869-A1 A2……………………for UK JIS K2204…………………………for JAPAN Before being filled into the engine fuel tank, the diesel fuel must be settled for a long period (normally at least 48h). - Page 5 2.5 Preparation Before Starting Before starting engine make sure that: There is no FUEL LEAKAGE There is no WATER LEAKAGE There is no OIL LEAKAGE There is no SMELL OF LP-GAS in the deep cavities of the boat or elsewhere The OIL LEVELS are correct The COOLING WATER LEVEL in the expansion tank for the fresh water system is correct.
-
Page 6: Engine Component Guide
3. Engine Component Guide 1. AIR FILTER 2. FUEL FILTER 3. SOLENOID 4. OIL SUMP PUMP 5. SEA WATER PUMP 6. OIL FILLER 7. ALTERNATOR 8. OIL FILTER 9. START MOTOR 10. WATER FILLER... -
Page 7: Running Instructions
4. Running Instructions 4.1 Starting the engine 4.1.1 Switch on the main switch, Start the engine room fan (if fitted) and allow it to run for several minutes before starting the engine. 4.1.2 Check the fuel cock and bottom sea water cock are in open position. Pump out any water in the boat with the bilge pump. - Page 8 4.1.4 Cold start: Turn the starter key to position ON. The lamps of REV meter and oil pressure light up. 4.1.5 Press the test button to make sure that the alarm is working. 4.1.6 Turn the starter key to position 1, the solenoid will release the fuel pump. 4.1.7 Turn the starter key to position heater and keep for 3 seconds, turn the key to position start, the start motor will work, release the key when the engine has started.
- Page 9 4.1.10 The single control lever combines the throttle and gear shift functions. F= Forward R= Reverse N= Neutral T= Throttle WARNING! Never change travel direction before the engine has returned to idling speed. For best results, do not run the engine at maximum revolutions for long periods. 4.1.11 Stop the engine by key switch at once if the alarm sounds and the signal lamps light up.
-
Page 10: Shutdown Procedure
4.1.13 Note: Do not switch off the main switch before the engine has stopped. 4.2 Shutdown Procedure 4.2.1 Before shutting down the engine, it should be allowed to idle for a few minutes, with the control lever in the neutral position. 4.2.2 Stop the engine by key switch when the engine is idling. -
Page 11: Checks And Service
4.1 Frost Risk If the engine is fitted with a fresh water cooling system, it should be filled with a 50:50 mixture of anti-freeze and water, or alternatively drained off. 4.2 Draining off fresh water systems To drain off the fresh water cooling system, open the cock on the side of the engine block. 4.3 Draining off sea water systems Unfasten the cover on the sea water pump. -
Page 12: Check Every 14 Days
5.1.2 Check water cooling level (Fresh water systems) Check every day before starting the engine, you open the cap of filler that the water level can be found from this filler. When necessary, fill up with fresh water or corrosion inhibitive anti freeze mixture. When there is a danger of frost it is important to ensure that the fresh water system is filled with anti freeze. -
Page 13: Service Every 50 Hours Of Operation
5.3 Service every 50 hours of operation 5.3.1 Change oil filter Run the engine until it is warm. Pump up the oil through the hole for the dipstick, and then refill with oil to the correct level. See: “Technical Data” for type of oil to be used. Note: The oil filter should be changed at the same time as every second change of engine oil. - Page 14 5.4.4 Check/change the impeller The impeller may become damages, for example through lack of water in the pump due to blocked intake. Close the bottom cock. Then remove the pump cover and inspect the impeller. If it has been damaged it should be replaced.
-
Page 15: Laying-Up And Launching
5.4.7 Check cooling system If the cooling system is functioning normally, the “TEMP” lamp will not be lit up. If the temperature is too high and the lamp lights up, the cause maybe one of the following: Blocked water intake Defective impeller in sea water pump Defective thermostat or temperature gauge Warning: Watch out for water leakage whenever you are working on the cooling system... - Page 16 6.3.5 Clean the filter screen and vent the fuel system 6.3.6 Loosen the venting screw on the fuel filter about 4 turns. Watch out for fuel splashing. 6.3.7 Pump up the fuel using the hand primer until the fuel is flowing out free of air bubbles. Tighten the venting screw again.
- Page 17 Check that fuel is reaching the injectors by unscrewing the pressure pipe on the injector, and then turn the engine over using the starter motor. If no fuel appears it may mean that the filter is blocked, the fuel pump is defective, or that there is air in the system. Change all the filters and vent the system. If not fuel appears after this, either the feed pump or the injector pump maybe defective.
-
Page 18: Technical Data
8 Technical Data Model MP-321 Type In-line, Water-cooled, 4-stroke Combustion chamber Swirl chamber Type of cylinder liner Number of cylinders Bore(mm) Stroke(mm) 78.4 Displacement(L) 1.123 Compression ratio 22:1 Firing order 1-2-3 Rated output/speed (kw/r/min) 15.5/3000 Max. torque/speed(N.m/r/min) 55.5/2100 Min. fuel consumption(g/kw.h) Lube oil consumption(g/kw.h) - Page 19 Intake valve opens 8°before T.D.C Intake valve closes 42°before T.D.C Valve timing Exhaust valve opens 42°before T.D.C Exhaust valve closes 14°after T.D.C Intake valve (mm) 0.15~0.20 Valve clearance (cold) Exhaust valve (mm) 0.15~0.20 Max. speed (r/min) 3240 Idle speed (r/min) Fuel injection timing (°) 14-17 Injection pressure (MPa)
-
Page 22: Electric Wiring Diagrams
9. Electric Wiring Diagrams...
