KMCTC-24, KMCTC-36, KMCTC-48
Gas Countertop Charbroiler
This manual contains important information regarding your
Kitchen Monkey unit. Please read this manual thoroughly prior to
equipment set-up, operation and maintenance. Failure to comply
with regular maintenance guidelines outlined in this manual may
void the warranty. PLEASE READ!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kitchen Monkey KMCTC-24
Summary of Contents for Kitchen Monkey KMCTC-24
- Page 1 This manual contains important information regarding your Kitchen Monkey unit. Please read this manual thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with regular maintenance guidelines outlined in this manual may void the warranty. PLEASE READ!
-
Page 2: Installation
WARNINGS Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other equipment. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation and maintenance instructions thoroughly before installing or servicing this equipment. Have the equipment installed by a qualified installer in accordance with all federal, state and local codes. -
Page 3: Lighting The Pilot
Gas Conversion: Conversion from Natural Gas to Liquid Propane (LP) or vice versa may only be performed by the factory or its authorized service agent. In case of troubleshooting, ensure the correct orifice sizes of the spuds have been provided. Natural Gas Orifice is #45 Liquid Propane Gas Orifice is #54 Orifice size is marked on the spud... -
Page 4: Operation
Install equipment under efficient exhaust hood with flameproof filters with a distance of no less than 4 feet between the top of the equipment and the filters or any other combustible materials. SPECIFICATIONS: Model Description Burners BTU/hr Gas Type KMCTC-24 Gas Charbroiler 24” 80,000 Natural or LPG* KMCTC-36 Gas Charbroiler 36” 120,000 Natural or LPG* KMCTC-48 Gas Charbroiler 48”... - Page 6 Countertop Gas Charbroiler - KMCTC-24, KMCTC-36, KMCTC-48 Reference KMCTC-24 KMCTC-48 KMCTC-36 Description Number Part Number Part Number Part Number CTC-1 CTC-1 CTC-1 Grate CTC-2 CTC-2 CTC-2 Radiant Cover Heat Insulation Plate - Chamber Front Plate Heat Insulation Plate - Side...
- Page 9 KMCTC-24, KMCTC-36, KMCTC-48 KMCTC-24 KMCTC-36 KMCTC-48...
- Page 10 Specific Instructions for charbroiler: 2. Lift off the complete grill plate assembly to expose the burners and valves.
- Page 14 Kitchen Monkey Equipment is warranted for one year, effective from the date of purchase by the original owner. A copy of the original receipt or other proof of purchase is required to obtain warranty coverage. This warranty applies to the original owner only, and is not assignable.
