- Page 1 15"17"20"LCD TV USER'S MANUAL TFT-LCD TV High Brightness & Contrast NICAM/A2 Stereo Sound MODEL:TOM1003 Please read this manual carefully before using your television and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
AC Mains lead, and Batteries. Before connecting the LCD-TV and turning the power on, please read this book carefully. Please keep this book for later use. If the Tv stops working it may be because of Electrostatic charge. Turn the set off completely and wait a few moments before turning it on again. -
Page 3: Safety Notice Items
Safety Notice Items "DO NOT LEAVE YOUR TV IN STAND-BY OR OPERATING WHEN YOU LEAVE THE HOUSE” Incorrect use may cause fire or electric shock. To prevent this, please do as required when you are installing, using and cleaning this machine. To insure... -
Page 4: Front Panel Controls
Volume up / Right orientation to adjust the item/Press to enter the submenu. 4. CH- TV channel down / to select the item in the menu TV channel up / to select the item in the menu 5. Power supply switch 6. -
Page 5: Connection Options
DC Power Cord Socket This TV operates on DC power. The voltage is indicated on the Specifications page . Never attempt to operate the TV on AC power. SCART Input Connect to the DVD/ VCR/broadcasting receiver or other... -
Page 6: Remote Control Key Functions
Remote Control Key Functions When using the remote control, aim it towards the remote sensor on the TV Illustration of the keys on the remote control: POWER Power supply switch MUTE 2. MUTE Display current input signal information 3. DISPLAY TV channel number select 4. -
Page 7: Installing Batteries
Note: The buttons on the Tv :-( MENU , VOL+/- , CH+/- , TV/AV,POWER) correspond with buttons ( MENU, V+/- , P+/- , TV/AV , POWER ) on the remote controller. Installing Batteries 1.Slide open the cover of the battery compartment on the back of the remote control. -
Page 8: Connection Instructions
You may also need to purchase and install a signal amplifier. If the antenna needs to be split for two TV s, install a 2-Way Signal Splitter in the connections. If the antenna is not installed properly, contact your dealer for assistance. -
Page 9: Basic Operating Instructions
You can use the number keys on the remote control to directly select TV channels. The TV can store up to 100 channels , and you can press the keys on the remote control or on the panel to make a selection. -
Page 10: Tuning Tv Stations
"Fine Tune" will change as the frequency increases. 6. When a station is found, using a "TV Guide" check that this is BBC1, if not press V+ to continue searching until BBC1 is located and is a good signal. -
Page 11: Tv Menu Options Continued
BBC1 ( Always start with the lowest number). b). Move the cursor to Highlight "TO" and using the V+ / V- select "1". c). Use the P- button to select "SWAP" and press "V+". The Tv will now switch back to the "TV Menu". -
Page 12: Menu Operations
Menu Operations 1. Press MENU button to either display the PC MENU or TV MENU or VIDEO MENU or GENERAL MENU or AUDIO MENU when different source inputs are selected. 2. Press P+/P- to scroll through the parameters 3. Press V+/V- buttons to make changes to the parameters 4. -
Page 13: Picture Menu Options Continued
Menu Operations Picture Menu Options Continued PC MODE COLOR SETTING. This operates in a different way. You may change each colour separately. Press V+/V- to select between 9300K/6500K/USER define . You could adjust the color values in USER mode . And the menu display is as follows: AUTO CONFIG : Is used for automatic adjustment of picture location frequency and phase parameters . -
Page 14: Sound Menu Options Continued
Menu Operations Sound Menu Options Continued. Function : VOLUME : Adjusts the volume of your TV BALANCE : Adjust the balance of the audio output from left to right . Normal setting is 50 for perfect balance. AUDIO PRESET : Press V+/V- to select between PERSONAL, VOICE, MUSIC and THEATRE . -
Page 15: General Menu Options Continued
OFF, LOW, MID, HIGH.) 3. INPUT SOURCE : Displays the current mode . Modes to select are :- PC- RGB , AV , S-VIDEO TV and SCART . 4. TXT LANGUAGE: To select the teletext languages. -
Page 16: Teletext
TELETEXT Some menu related functions are not available in TELETEXT mode. MENU and AUTO AD control functions are not available in TELETEXT mode. If the TV is switched on by POWER after being switched off in TELETEXT mode, or press TV/AV or PC button, the TELETEXT mode will cancel automatically. -
Page 17: Teletext Continued
TEXT Button Press TEXT to enter Teletext mode and only the text page can be visible . MIX Button Press MIX button to enter Teletext mode and both the TV picture and text page can be visible. TIME While in normal TV mode only, pressing the button TIME will display the... -
Page 18: Connection Instructions
Connection Instructions PC Setup You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied). Connection and use steps: 1.Read the user guide supplied with your computer and ensure that it has a VGA connector;... -
Page 19: Vcr Setup
1.Read the user guide supplied with your AV devices and ensure that it has Composite or S-Video connectors; 2.Make sure that the power of the LCD-TV and the AV device are off; Connection Option 1 Set the VCR to "TEST SIGNAL" and tune the Tv to the Test Signal in "Manual Tuning"... -
Page 20: Cable Tv Setup
Connection Instructions Cable TV Setup Cable TV or DVB (set top box)Setup - After subscribing to a cable TV service from a local provider or installing a "Freeview" box you can watch cable or "Freeview". To connect either of these boxes see the diagram below. -
Page 21: Help Guide
Poor I/R signal from handset Action Check connections to the external PSU and from the PSU to the Tv. Turn the Tv on with the Remote Control or the Power button on the Tv. Internal fault. Return to Store. Check the aerial connection. -
Page 22: Specifications
Specifications Specifications of the television that you have just purchased may vary from the information in this table due to technical innovations. Screen size (Diagonal) 15". 17". 20" "depending upon model" Resolution ………………………. 1024 x 768 Video Systems………….PAL / SECAM Sound Systems. - Page 23 V0.1 0090506962...
