LCD TV RECEIVER
Please read this manual carefully before
using your television and keep this manual
for future reference.
USER'S MANUAL
MODEL:
LCD19HDID-407W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD19HDID-407W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technika LCD19HDID-407W

Summary of Contents for Technika LCD19HDID-407W

  • Page 1 LCD TV RECEIVER USER'S MANUAL Please read this manual carefully before using your television and keep this manual for future reference. MODEL: LCD19HDID-407W...

  • Page 2: Table Of Contents

    S-VIDEO Input... SCART Input... HDMI Input... Wall Mounting... Basic Operating Instructions... Turn on the LCD-TV... Audio Control... Mute... Select the TV Channel ... Picture Mode... Program Swap... Program Scan... Menu Operations... Picture Menu Options... Audio Menu Options... Function Menu Options...

  • Page 3: Safety Notice

    Never put the unit in direct sunlight or near heat sources; Allow enough space for proper ventilation; Please keep water away from the LCD-TV . If water comes in to contact with the LCD-TV, disconnect the power cord from the power source, then wipe the set with a dry soft cloth;...

  • Page 4: Front Panel Control

    Volume down / Left orientation to adjust the item in the OSD VOL+ Volume up / Right orientation to adjust the item/Press to enter 5. CH- TV channel down / to select the item in the menu TV channel up / to select the item in the menu 6. Power indicator...

  • Page 5: Connection

    PC to the audio input port ANT IN AUDIO IN Earphone port Antenna Input Connect cable or antenna signals to the TV, either direc- tly or through your cable box. COMPONENT Input Connect a component video/audio device to these jacks S-VIDEO...

  • Page 6: Remote Control

    Remote Control Key Functions When using the remote control, aim it towards the remote sensor on the TV STANDBY SLEEP Q.VIEW AUTO AD DISPLAY -/-- P.STD MENU S SM SUBCODE MODE REVEAL SIZE TIME D.MENU TEXT SUBTITLE INFO Buttons on the remote control...

  • Page 7: Remote Control

    The batteries must be of the same type. The batteries must be located properly. The batteries are not rechargeable. If your TV is to be stored for a period of time, remove the batteries from the remote control.

  • Page 8: Connection Instructions

    To improve picture quality in a poor signal area, purchase and install a signal amplifier. If the antenna needs to be split for two TV s, install a in the connections. If the antenna is not installed properly, contact your dealer for assistance.

  • Page 9: Vga Input

    Connection Instructions VGA Input You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied). Connection and use steps: 1.Read the user guide supplied with your computer and ensure that it has a VGA connector;...

  • Page 10: S-Video Input

    1.Read the user guide supplied with your AV devices and ensure that it has S-Video connectors; 2.Make sure that the power of the LCD-TV and the AV device are switched off; Connection Option 1 Set VCR output switch to 3 or 4 and then tune TV to the same channel number.

  • Page 11: Scart Input

    2. Operate the corresponding external equipment. Refer to external equipment operating guide. Note: The audio cable included with the TV should be used when connected with PC/ COMPONENT/S-VIDEO. Wall Mounting Use 4 machine screws(M4x8mm not included) to mount...

  • Page 12: Basic Operating Instructions

    You can also turn on the TV from standby mode by pressing the digits(1-9) or P+/- . The display will appear on the screen when the TV is turned on for the first time: Press V+/- to adjust the region and P+/- to select the YES and MENU to confirm.

  • Page 13: Select The Tv Channel

    You can use the number keys on the remote control to directly select TV channels. The LCD-TV can store up to 100 channels , and you can press the keys on the remote control or on the panel to make a selection.

  • Page 14: Menu Operations

    2. Press P+/P- button to enter the picture menu and to go up and down to select the desired option . PC MENU PICTURE BRIGHTNESS CONTRAST SHARPNESS COLOUR TEMP. TV/S-VIDEO/SCART/DTV MENU BRIGHTNESS CONTRAST SHARPNESS COLOUR NOISE REDUCTION HDMI/COMPONENT MENU BRIGHTNESS...

  • Page 15: Audio Menu Options

    Menu Operations Picture Menu Options Continued 3.Press V+/V- button to increase and decrease the level to match your preference . 4. Repeat step 2 and step 3 until desired picture quality has been achieved . Functions: BRIGHTNESS :Adjust the brightness of the picture . By increasing the level, it will add more light to dark parts of the picture and by decreasing the level ,it will add more dark to light parts of the picture.

  • Page 16: Audio Menu Options

    4. Repeat step 2 and step 3 until desired sound quality has been achieved . Functions : VOLUME : Adjust the volume of your TV BALANCE : Adjust the balance of the audio output from left to right . When indication value of balance increases towards 100 , sound of the left speaker becomes weaker .

  • Page 17: Function Menu Options

    4. Repeat step 2 and step 3 until desired effect has been achieved . Functions: 1. INPUT SOURCE : PC , COMPONENT , HDMI , DTV, TV, SCART, S-VIDEO 2. TXT LANGUAGE: To switch the teletext languages. 3. TXT EAST/WEST: To select EAST or WEST .
  • Page 18 Menu Operations Function Menu Options Continued 4.DISPLAY MODE: To select the display mode between FULL SCREEN 5.BLUE SCREEN:To set On, the screen will be in blue screen after 3 seconds if there is no signal. 6. RESET : Press V+ to reset the settings to the factory default . 7.

  • Page 19: Adjust Menu Options

    Menu Operations Adjust Menu Options 1. Press MENU and V+/V- button until the following menu appears on the screen Note: This menu only appears in PC mode . 2. Press P+/P- button to enter the adjust menu and to go up and down to select the desired option 3.Press V+/V- button to increase and decrease the level to adjust the selected option to your preference .

  • Page 20: Tuning Menu Options

    1.TUNING PROGRAM: Press V+ to enter it and the TUNING PROGRAM menu appears: CHANNEL : Press V+/V- to change the TV channel . EDIT NAME: Press V+ to enter it , then press V+/- to select the position you want to edit and press P+/- to input the emblem such as character and so on.(There are 8...
  • Page 21 Menu Operations Tuning Menu Options Continued SKIP : If you want to skip a channel , press V+/V- to select ON , and this channel will be skip next time when you press P+/P- . But you can press digits button to select the channel . If you want to restore the channel , select OFF. AFC : Auto frequence control .

  • Page 22: Dvb-T Main Menu Operations

    DVB-T Main Menu Operations Press TEXT button to display the additional information. Press the DTV/TV button on the remote control to enter the DVB status. 1. Press D.MENU button to display the main menu 2. Press to scroll through the options 3.

  • Page 23: Favourite List

    DVB-T Main Menu Operations Favourite List 1. Press D.MENU button , the main menu will appear. 2. Press button to select Favourites and OK button to confirm enter the sub-menu. 3. Then press to select among List 1, List 2, List 3, List 4 and List 5. 4.

  • Page 24: Timers

    DVB-T Main Menu Operations (INFO)More: Press i button to display more information about operation when you need help and press again to exit the help. List Schedule EPG: Press button to select List Schedule EPG and OK button to enter the sub-menu :press these buttons to navigate the program list.

  • Page 25: Settings

    DVB-T Main Menu Operations Press button to select the other items, and then press the digits button to set the Start time, End time and Date. Press button to select Password and then press digits to set the password. 4. After you have set the timer, you could press the timer.
  • Page 26 DVB-T Main Menu Operations Settings (continued) Language 1. Press D.MENU button , the main menu will appear. 2. Press button to select Settings and OK button to confirm enter the sub-menu. 3. Press button to select Language and OK button to confirm enter the sub-menu.

  • Page 27: Teletext

    P+ or P- buttons, or the coloured Fast text buttons. Mix mode To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the Tv picture. Press this button again to return to Full text.
  • Page 28 Teletext on-line interactive puzzles. Time While in normal TV mode only, pressing the button display the teletext time in the top right hand corner for a few seconds. Fast text coloured buttons...

  • Page 29: Troubleshooting Guide

    2.The TV set must only be repaired by a qualified registered service person. Never attempt to remove the back cover as the TV set has dangerous voltages in side that may cause a fatally or fire. Verify if the television is properly plugged in.

  • Page 30: Specifications

    Specifications Specifications of the television that you have just purchased may vary from the information in this table due to technical innovations. Picture, sound system Audio output COMPONENT input PC input S-VIDEO input Audio input External input port SCART Power requirements Power consumption Temperature Humidity...
  • Page 31 V0.1 0090502138B...
