1. Introduction

GSM rele 5
The GSM-R5-DIN ( for short) is designed to be mounted on a DIN rail
into a switchboard. GSM rele 5 can control two independent electrical circuits in a
building e.g. circuit of an accumulator stove and circuit for garage gate control. The
Control is made via SMS messages or by ringing. After installation into an electrical box
insert a SIM card of any GSM operator and the device is ready to operate.
GSM rele 5
The has 2 digital outputs (Y5, Y6) with a relay, which can control directly
power circuits up to 230 V /5 A. It's possible to control directly e.g. a thermoregulator
AC
circuit of a gas boiler or a coil of one phase contactor 230V AC. The contact of the
contactor can then control either one phase high power appliance (e.g. electrical
radiator) or a coil of three phase contactor of an accumulation stove.
GSM rele 5
The has also 2 digital inputs (X1, X2) and 2 analog inputs (A3, A4).
Digital Inputs are determined for potencial free contacts. Analog inputs can be used for
measuring the temperature, current or voltage.
regulators which use analog inputs from temperature sensors to maintain preset
temperature. The temperature of sensors can be readout via SMS.
There is an internal built in Li-POL accumulator which allows to send an SMS in case
of a power failure and to restore the output status after a power failure. It's also possible
to monitor the status of inputs and temperatures via SMS during 230 V
Internal data logger keeps records about events and valued of inputs.
① - device state indication
② - OUTPUT Y5, Y6 connectors
③ - 230V Power supply connector
AC
④ - Push buttons, local control from Y5, Y6
⑤ - OUTPUT Y5, Y6 state indication
⑥ - INPUT X1, X2 connectors
⑦ - ANALOG INPUT A3, A4 connectors
⑧ - GSM antenna connector
⑨ - USB connector (for configuration)
⑩ - nano SIM card holder
2. Package
Content
 1 pc GSM rele 5 (order code
GSM-R5-DIN)
 1 pc GSM antenna ANT05S (order code GSM-ANT05S)
 1 pc temperature sensor GSM-C-T2 (based on KTY81-
210), cable - 1 meter

3. Installation

GSM rele
1. To operate the
card must be functional and active. Also some credit is necessary if SIM card is pre-
paid. We recommend to deactivate the PIN code for installation.
2. The SIM card holder can accommodate nano SIM card only (12,3 x 8,8
1. Before inserting the SIM card into the
recommend to turn off setting of the "PIN code"!
2. Insert the active SIM card (= at least one call was made) to any mobile
telephone and turn off the requirement of setting the PIN. On most
mobile telephones, this option can be found in menu "Setting the
telephone protection". or "Setup -> Security -> PIN control".
ATTENTION:
3. GSM rele5 must be mounted by qualified personnel only!
mm).
3. Insert this prepared SIM card (cut off
corner first) into a SIM card holder. The
proper insertion is indicated by a slight
mechanical click noise. To remove the SIM
card - press the SIM card in direction into the
GSM rele 5 until mechanical click. The SIM
card can be the freely removed.
4. Now it's possible to connect the device to 230V AC power supply. If the
power supply is correct, green LED PWR goes on and blue LED GSM is flashing
slowly. After about 20 seconds, blue LED diode GSM starts flashing with a period 1
per 3 sec. (registered).
GSM rele
5. For the first tests of
important. Please keep in mind that the devices connected to OUTPUTS will be
switched on during tests!
GSM rele 5
6. To test the press the push button bellow Y5 for a local control.
The yellow LED diode for Y5 lights ON and relay for output Y5 switch on. Send an
SMS from mobile phone (which will be mainly used to control the
form 1234 OFF to the telephone number of the SIM card inserted into the
GSM rele 5
. This will switch off output Y5 and the yellow status LED for Y5 goes
OFF. Simultaneously, the device automatically sends a confirmation SMS message
on performing the operation. The password 1234 can be changed later in
GSM rele 5
Configuration. The reacts on the SMS text message from any telephone
GSM-R5-DIN_User_Manual_EN_v1-11.docx
GSM rele 5 has built in two automatic
AC
5
a SIM card of any GSM operator is necessary. SIM
GSM rele 5
device, we
5
the connection of inputs and outputs is not
as long as the access password matches. The very first one (the sender of the first
valid SMS message) will be remembered as master and will receive messages about
GSM rele
events on
device.
7. Try "ringing" on device. You can make pulse on Y6 for approx. 4 seconds by
GSM rele
calling to
makes pulse on the Y6. This pulse can be used for example for opening entrance
gate. To test this function call from the phone (which was used to send the first
test SMS to switch off the Y6). The pulse is indicated by yellow LED below Y6 push
button.
8. Try regulation. By default the regulation of Y5 depends on temperature
sensor connected to analog input A3. So connect a temperature sensor into a
analog input A3. Send SMS in form of 1234 Y5 REG 25 to command the device to
maintain temperature to 25°C. The range of regulation is between 0°C and +55°C.
Regulation can be canceled by SMS with command 1234 Y5 OFF.
9. A default factory setting of the
form 1234 !FACTORY. If you made a backup configuration in SeaConfigurator
, your setting can be then restored from backup configuration of SeaConfigurator
program.
10. Names of input, outputs (and its states) and names of commands is possible
to change in SeaConfigurator program. Visit
for free and install the program to your PC.

4. Technical Specifications

power failure.
Parameter
Width
Dimensions Height
Depth
Power Voltage
supply *1) Consumption
Backup
power supply
Digital inputs
Voltage
Digital
outputs Current
Power
Analog inputs
Resolution
GSM module Frequencies
Humidity
Storage
Temperature without supply
Operational
GSM rele 5
Use - DIN inside the rack with IP44 or better!
*1) Use breaker max. 10 A before
1 mm 2 .
*2) The GSM rele 5
24 hours (due to internal accumulator).

5. Hardware

5.1

Connectors

2 digital inputs, 2 analog inputs and 2 digital outputs
can be connected
L, N – main power supply 230 V AC
Y5, Y6 – digital outputs
A3, A4 – analog inputs
X1, X2 – digital inputs
Analog inputs can be used for temperature
measurement using KTY81-210, PT100 or PT1000
sensor. Length of wires to the sensor is not limited,
but be aware of resistivity of these wires. For KTY81-
210 16 Ω means 1°C.
ATTENTION: Do not exceed the parameters of
inputs and outputs – Chapter Tech. Specification.
For examples of connection see the chapter
Examples of connection.
GSM rele 5 ) in
5.2

Buttons

GSM rele 5
has two buttons on front panel for local control of outputs Y5 and Y6. Every
click on a button change state of corresponding output. Example: If output Y5 was
5
. This user can also control the device by "ringing" on the
5
(with default factory setting). The device hangs up the call and
GSM rele 5
www.seapraha.cz
Symbol Cond. MIN.
W
H
D
V
integrated
X1, X2 – potencial free contact
Y5, Y6 – relay
V
OUT
I
OUT
A3, A4 - set by user as:
Voltage 0-10V;
Current 0-20mA (input resistance 75);
temperature for sensors:
KTY (-50 to +150°C);
Pt100 (-100 to +300°C);
Pt1000 (-100 to +300°C)
tA
GSM rele 5
. For power supply 230V
has to be connected to 230V power supply every 3 months for
AC
GSM rele 5
.
can be recovered by an SMS in
for download it
TYP. MAX. Units
52 mm
90 mm
66 mm
180 230 250 V AC
1 2 W
1 day
250 V AC
30 V DC
5 A
1250 VA
150 W
12 bit
850/900/1800/1900 MHz
90 %
3 *2) months
-20 +45 °C
!
use lines min.
AC
