Summary of Contents for Askey AP5660W
- Page 1 AP5660W User Manual Page: 1...
-
Page 2: Table Of Contents
Login web page ................4 2.2. Change your WiFi Setting and Setup with Mesh ......5 [CAP] refers to your AP5660W(CAP mode)..........6 [RE] refers to the extender................6 [STA] refers to the Desktop/Laptop/Mobile connected to your device or extender through SSID and Password. -
Page 3: Getting To Know Your Ap5660W
1. Getting to know your AP5660W LED Indicator ① WPS Button ② Reset Button ③ LAN Port ④ Power Plug ⑤ Front Panel LED State of Router Power off Red Solid -> Booting up Green Blinking until System is available... -
Page 4: Installation
2.1. Login web page 1. Plug in adapter power 2. Connect the PC Ethernet cable to LAN port. 3. Launch your web browser and enter the AP5660W’s default address: 192.168.1.1 4. Enter the default username(admin) and password(admin) to log in to your device’s management page. -
Page 5: Change Your Wifi Setting And Setup With Mesh
2.2. Change your WiFi Setting and Setup with Mesh 1. Login the AP5660W Web GUI, then select “Mesh” on Network list. 2. On “BASIC” tab, you can see AP Mode default is “RE”, change Mode to “CAP”, and enter your “WiFi Network Name”, “WiFi Password”, “Security Setting”. -
Page 6: [Cap] Refers To Your Ap5660W(Cap Mode)
3. Connect AP5660W to Router LAN port by Ethernet. And wait LED from “Blue blinking” to “Blue solid”. 4. Power on other AP5660W(default is RE) and wait LED to “Green solid”. 5. Press AP5660W(CAP) WPS button.(Green and Blue LED alternate blinking). -
Page 7: Web Gui
3. Web GUI 3.1. Dashboard 1. “Network Status” will show Smile Face when AP5660W stands for connecting the Internet successfully. 2. “Mesh Network” is shortcut for MESH management page. Page: 7... - Page 8 3. “System Information” includes “System Information”, “LAN Information”, IPv6 Information”, “Wireless Information”. Page: 8...
- Page 9 4. “System Settings” is shortcut for System Settings page 5. “Connected Devices” will show Devices Information which device in the LAN Network. Page: 9...
-
Page 10: Network
3.2. Network AP5660W support CAP mode (Controller AP) and RE mode (Range Extender), when AP5660W was CAP mode, the Mesh Page will include extra functions, “WiFi Setting” and “Topology”. Page: 10... -
Page 11: System Settings
3.3. System Settings 1. “Password & Timeszone” includes “System Password”, “Time Zone”, “Web Auto Logout”, “NTP Server” settings. 2. “Reboot” Page: 11... - Page 12 3. “Configuration & Reset” 4. “Firmware” Page: 12...
- Page 13 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
