- Page 1 IMPORTANT: Read before Using W068021 100FT/40M LASER DISTANCE MEASURE Questions, problems, missing parts? Before returning to your retailer, call our customer service department 1-877-876-7562 8 a.m. – 5 p.m., EST, Monday – Friday. www.workprotools.com...
-
Page 2: Table Of Contents
FCC statement (applicable in U.S.) ------------- Measuring Functions ------------------------- Laser classification ---------------------------------- Measuring single distance------------------------ Labelling ------------------------------------------------ Warranty ------------------------------------------ Continuous measuring------------------------------ Area------------------------------------------------------ Volume-------------------------------------------------- Pythagoras(2-point)---------------------------------- Pythagoras(3-point)---------------------------------- Clear----------------------------------------------------- Addition/Subtraction --------------------------------- Technical Data ----------------------------------- Message Codes --------------------------------- Care ------------------------------------------------- Disposal ------------------------------------------- WORKPRO W068021... -
Page 3: Instrument Set-Up
Display Main line Units Insert batteries On/ Measure / Continuous Change measuring batteries when Clear / Off battery symbol Units / is empty. Measuring Reference Area / Volume/ Add/Sub Pythagoras(2-Point /3-Point) WORKPRO W068021... -
Page 4: Operations
0 1/16 in 0.00 ft Change the measurement reference -The measurement The system Press button and the system default to change the measurements recovery to initial reference to start at the setting. top for bottom as a measurement. reference point. WORKPRO W068021... -
Page 5: Measuring Functions
Stops continuous measuring. 39.99 Aim active laser at target. Area The result is shown in the main line and the measured UNITS distance above. 24.352 m Aim laser at first Aim laser at target point. second target point. WORKPRO W068021... -
Page 6: Volume
78.694 m Pythagoras(2-point) The result is shown in the Aim laser at Aim laser at main line and 25.286 m first target 90° 90° second target the measured point. point. distance above. WORKPRO W068021... -
Page 7: Pythagoras(3-Point)
The result is Measure Press the “+”or “-” Then shown in the main line and the first button to measure —20.000 29.999 m 20.000 m 9.999 the measured data. add/subtract next distance measurement from second above. the previous data. data. WORKPRO W068021... -
Page 8: Technical Data
(such as bright sunlight, targets with poor reflectivity, or high or low temperatures) the measurement uncertainty could further increase up to ± 4 mm for distances below 5 m and additionally by roughly 0.15 mm/m for distances greater than 5 m. WORKPRO W068021... -
Page 9: Safety Instructions
The device is designed for use in installations which are unprotected areas permanently habitable by humans. • Aiming directly in the sun Do not use the product in explosion hazardous areas or in aggressive environments. WORKPRO W068021... -
Page 10: Areas Of Responsibility
• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WORKPRO W068021... -
Page 11: Laser Classification
Looking directly into the beam with optical aids (e.g. binoculars, telescopes) can be hazardous. WARNING The WORKPRO W068021 has a two-year warranty. For further information on this, contact your dealer. This warranty is void if product is used for Batteries: 2 x AAA WKM-40L commercial purposes.
