INSTRUCTION MANUAL
OIL-FREE SCROLL VERTICAL PUMP-MOTOR
ASSEMBLY
SLVB-5
Thank you for purchasing our oil-free scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLVB-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Anest Iwata SLVB-5

  • Page 1 INSTRUCTION MANUAL OIL-FREE SCROLL VERTICAL PUMP-MOTOR ASSEMBLY SLVB-5 Thank you for purchasing our oil-free scroll air compressor. ●Before operation, be sure to read this instruction manual thoroughly for safe and efficient use for a long operating lifetime. ●After reading it, store in a convenient place for immediate and future reading.
  • Page 2: Important Information And Safety Precautions

    Important information and Safety precautions ▪ Important information Read all important information and safety precautions before use. The operator shall be fully knowledgeable of the requirements stated within this instruction manual, including important warnings, cautions and operation. Read manual before performing any maintenance. Keep this booklet in an appropriate place for immediate reference.
  • Page 3: Safety Precautions

    Important information and Safety precautions ▪ Safety precautions WARNING Install in a safe area. To prevent a fire or explosion, install in an area free of flammable gases or organic solvents. Never install outdoors. To prevent fire or electric shock, never install outdoors. Turn off the main electric source.
  • Page 4 Important information and Safety precautions WARNING Not for use as life support. Serious bodily injury and/or death may occur. Unit must only be used to compress air. Do not touch. Keep hands and fingers away from fans, pulleys and belts while the power is on. Serious injury, including entanglement of fingers or hands can occur.
  • Page 5 Important information and Safety precautions CAUTION Use at ambient temperatures of 36°F to 104°F. Drain will freeze at less than 36°F and will cause unit failure. Using over 104°F will cause a shorter lifespan or unit damage. Use in an area free of dirt and dust. Failure to do so may result in equipment failure.
  • Page 6: Table Of Contents

    Contents Important information and Safety precautions ■Important information ---------------------------------- 2 ■Safety precautions --------------------------------------- 3 ■Contents ---------------------------------------------------- 6 Installation ■Precaution about installation ---------------------------- 7 ■Installation space ---------------------------------------- 8 ■Ventilation ------------------------------------------------- 8 Test operation ■Operation -------------------------------------------------- 9 Maintenance and inspection ■Pump-Motor Assembly maintenance standards ----- 10 ■How to carry out maintenance ---------------------------- 11 ■Troubleshooting Guide -------------------------------------- 12 Specifications...
  • Page 7: Installation

    Installation ▪ Precautions about installation WARNING! Do not use in an area which is exposed to rain, steam or high humidity. High humidity can cause electric shock or fire. Do not install in an area with corrosive gas (ammonia, acid, salinity, ozone gas and sulfur dioxide) preventing a shorter lifespan of the unit.
  • Page 8: Installation Space

    ▪ Installation space Secure the space around the compressor for safe inspection and maintenance. Installation space (inch) Above Front side Other Sides ▪ Ventilation When using in an enclosed room, install a fan for ventilation. British Thermal Unit Model (BTU) SLVB-5 12800...
  • Page 9: Test Operation

    Test operation ▪ Operation ❖ Preparation (1) Make sure all safety warnings, labels, and instructions have been read and understood before continuing. (2) Make sure any shipping materials, brackets, etc. are removed. (3) Check that the electric power source and ground have been firmly connected (4) Make sure all pressure connections are tight.
  • Page 10: Maintenance And Inspection

    Maintenance and inspection Carry out the following maintenance and inspection items according to the schedule below. This interval is based on conditions where ambient temperature is at around 86°F. If your location is warmer or running condition is severe, maintain at a shorter period. During warmer conditions, shorten the period approximately 30 % from our recommendation at every 9°F.
  • Page 11: How To Carry Out Maintenance

    An exclusive tool is necessary to measure belt tension. Ask our distributor to readjust belt tension when needed. Readjustment Replacement new belt Readjustment Model target load / Hz target load / Hz standard load / Hz Tolerance ±5 Tolerance ±5 SLVB-5...
  • Page 12: Troubleshooting Guide

    Troubleshooting guide If you have any problems, please refer to the below chart. ( * ) marked items may be difficult to remedy and require technical support. Please contact distributor for assistance. Problem Cause Corrective action Electric source is not ON. Turn on electric source Compressor unit does Electric source is not connected...
  • Page 13: Specifications

    Specifications ▪ Pump-Motor Assembly specifications Model SLVB-5 Item Pump model SL-165E-US 100 psi @ 208V Max Working pressure (psi) 115 psi @ 230V Air delivery (cfm) 14.8 Driving system V-belt Discharge air temperature (°F) Ambient temperature + less than 342 Air outlet ½”...
  • Page 14: Appendix

    Appendix ▪ Outer dimensions...
  • Page 15: Warranty

    SHALL ANEST IWATA AIR ENGINEERING BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTAL, PUNITIVE, SPECULATIVE OR INDIRECT LOSSES OR DAMAGES WHAT SO EVER ARISING OUT OF OR IN ANY WAY RELATED TO ANY OF THE PRODUCTS OR GOODS SOLD OR AGREED TO BE SOLD BY ANEST IWATA AIR ENGINEERING TO BUYER. TO THE EXTENT ALLOWABLE UNDER APPLICABLE LAW, ANEST IWATA AIR ENGINEERING’S LIABLITY IN ALL EVENTS IS LIMITED TO AND SHALL NOT EXCEED THE PURCHASE PRICE...
