- Page 1 CONSTRUCTION L - 03 MANUAL 安装时间/Time to build：6hours 最大载重/Max weight：30Kg...
- Page 2 Tighten the bolts with full force to prevent them coming loose. M8x20=4 320mm 产品中一共包含两种定位块， The positioning blocks are some of the smallest parts but they 它是至关重要的部件，请仔细 also some of the most important. 分辨，避免漏装或误装。 Putting them in the right place is a key of the DOCYKE. 200mm...
- Page 3 M8x20=2 240mm 装配零件前先检查螺母 是否放置正确。 110mm Check the profile nut remains perfectly straight in the slot.
- Page 4 M8x32=2 M8=2 There are two types of knurled discs. One can be installed in 5°, 15°, 25°, etc. The other can be installed in 0,10°,20°,30°,etc. 角度片的齿型分 2 种， 一种可安装成 5°,15°,25°,,,， ，等 一种可安装成 0，10°，20°, 30°， ，等 30°...
- Page 5 Screws are required to use different lengths in different locations, so be sure to follow the instruction manual and Hex wrench handle use the to tighten the screws. M8X20=2 60mm M8=4 M8X32=4 30° 30°...
- Page 6 M8X20=2 M8X20=2 40mm...
- Page 7 M8x20=2 320mm M8x20 M8x25 120mm...
- Page 8 M8x32 55°...
- Page 9 Each increment is 5° ， 5x 齿轮座每一格旋转的 最小单位是 5 度。 knurled increments. M8x40 M8X40=4 留 2mm 的调整余 量 ， 转 动 25 ° （5 格）调 整好 位置后再拧紧。 25° 39mm 25°...
- Page 10 M8X20 200mm M8X40 M8X32=4 45° M8=4 55° M8x20=2...
- Page 11 M6=2 M8x25 360mm M8x25 M6x35=2...
- Page 12 M8X20=4 120mm M8X20=2 280mm M8X20=2...
- Page 13 M8X20=2 M8X20=3 A side...
- Page 14 重复这一步骤，组成 2 套轮子（左右轮对称布置） 。 Repeat this step to make two sets of wheel assemblies (symmetrical arrangement of left and right wheel assemblies). A side M8X50 ø8Xø30xh2 ø8Xø16xh1.6 M8X75...
- Page 15 M8X60 ø8Xø16xh1.6=2 M8X60=2 M8=2...
- Page 16 M6=2 M6X25=2 M8x25 M8x50 418mm ø8Xø12xh6 ø8Xø30xh2 M8x20 M8x40...
- Page 17 拉杆螺纹分左旋（红点）和右 旋（绿点） 。请对应安装。 The thread is divided into right- handed (red dot) and left-handed (green dot). 调整轮子的平行度，螺母锁紧，避免 松动。 Adjust the parallelism of the wheel, then lock the nut, to avoid loose.
- Page 18 M8X60 360mm M8X20...
- Page 19 M8X40 160mm M8X20 M8x32 80°...
- Page 20 M8X40=2 M8X20 80mm 先不需要拧紧，留 2mm 左右余 量,用于齿座的角度调节。 Do not need to first tighten, stay 2mm for angle adjustment. M8X20...
- Page 21 M8X25 M8X32 30°...
- Page 22 ø19Xø32xh40 ø19Xø32xh10=2 M8X20=2...
- Page 23 M8x20=2 M8x20=2...
- Page 24 ø19Xø32xh10=2 M8x20=2 222mm Ø8Xø30xh2=2 Ø19Xø32xh2...
- Page 25 Ø19Xø32xh2 Ø19Xø32xh10=3 M8x20=2 172mm Ø8Xø30xh2=2 M6x25=4 M6=4...
- Page 26 橡胶链条拉紧后再用螺丝 M8x20=2 拧紧。 Tensioned with full force, then tighten bolts well 1648...
- Page 27 M8x20 160mm M8x20 M8x20 M6=2 M6x25=2 M8x20 M8x20=2 40mm...
- Page 28 M8x20=2 M8x32=2 M8=2 20°...
- Page 29 M8x20 Ø19Xø32xh5=4...
- Page 30 M6X14=4 M6x20=2 A side M8X20=2 调整刹车片与刹车盘的间隙， 并拧紧螺丝。 Adjust the gap between the brakes and the brake disc and tighten the screws.
- Page 32 如果您有任何问题，或者更好，更酷的创意，欢迎联系我们。 If you have any questions, or better ideas, welcome to contact us. www.DOCYKE.com 1200mm...
