Summary of Contents for Rivacold RCMR 350
- Page 1 ’ ’ ’ ’ Ø Ø RCMR Rev 02 02 13...
- Page 2 Name of the Manufacturer: Rivacold s.r.l. Address: Via Sicilia, 7 Fraz. Montecchio 61022 VALLEFOGLIA (PU) Telephone: (+39) 0721 919911 Telefax: (+39) 0721 490015 Company R . - All rights reserved IVACOLD S These assembly instructions are entrusted to the users of the C...
-
Page 3: General Details
1.1 General details These assembly instructions are an integral part of the C RCMR (which are identified in this document with the EILING CUBIC UNIT COOLERS term ) manufactured by company R .; for this reason, they must be part of the technical file of PARTLY COMPLETED MACHINERY IVACOLD S the final machine into which this... -
Page 4: Warranty
1.2.5 Typographical conventions The graphic layout of these assembly instructions is such that it allows the reader to easily recognize the contents; with this mindset, for example, the instructions are associated to lists, as indicated below: this symbol identifies a generic bulleted list or one formed by simple actions (the order in which the actions are listed is not mandatory, but highly recommended);... -
Page 5: Request For Assistance
1.3.3 Operations that entail Expiry of the Warranty Any attempt to disassemble, modify, or tamper with a component of the made by the User or by PARTLY COMPLETED MACHINERY unauthorized personnel entails expiry of the warranty and absolves the Manufacturer of any responsibility concerning any possible damages to persons and things a like that stem from such tampering. -
Page 6: Lifting And Transport
3.Safety and Technical Data 3.1 General details on Safety 3.1.1 Engineering Criteria When engineering the , the principles and concepts have been adopted, introduced by the pertinent PARTLY COMPLETED MACHINERY paragraphs of the harmonized norms indicated in Chart 1. Chart 1 – Main harmonized norms used when engineering the PARTLY COMPLETED MACHINERY NORM TITLE... -
Page 7: Installation And Hook-Up
3.3.1.3 Cautions to be followed during Lifting and Transport During the lifting and transport phases, the cautions described in this paragraph must be followed. For these operations, only designate specialized personnel trained concerning the procedures to handle machineries and capable of choosing and safely using the lifting and transport devices most suitable to the given circumstance (e.g. hoist, lifts). Check and, if need be, make sure that all the parts that can move are properly fastened (or, if required, removed and reassembled when the operation is completed). - Page 8 alternatively, disconnect the entire unit from the line provided by the customer); moreover, check that any possible residual energy has been de-charged before performing the interventions. As much as possible, operate on the and on the piping only after having emptied them and, before PARTLY COMPLETED MACHINERY proceeding to restart it, make sure the system is thoroughly cleaned.
- Page 9 Be careful for sharp cutting parts and when cleaning the air-cooled evaporator 3.5 Proper and improper use of the partly completed machinery is designed and built to be inserted in a refrigerating circuit that can be used in the field of industrial PARTLY COMPLETED MACHINERY and commercial refrigeration in a permanent site.
-
Page 10: Technical Data
DANGER: it is necessary to make sure that before starting any type of intervention on the PARTLY COMPLETED or near its components or accessory equipment, the power supply be cut-off; if this were MACHINERY not possible, it is necessary to take measures that, at any rate, allow operators to safely work near PARTLY COMPLETED MACHINERY DANGER: unauthorized tampering with or replacement of one or more parts of the... -
Page 11: Transport And Handling
Before proceeding to incorporate the into the final machine, you must, however, arrange the power PARTLY COMPLETED MACHINERY supplies and the utilities necessary for the system to operate properly, following the indications reported in this Chapter and, if necessary, consulting the Technical Office of the Manufacturer first. ATTENTION: the user, once the equipment has been purchased and before its use, becomes responsible for the component, subjected to Directive 97/93/CE (PED), and must perform the inspections by law in... -
Page 12: Installation
4.3 Installation DANGER : the Manufacturer rejects any responsibility for possible damages to things and/or persons stemming from improper interventions performed by unqualified, untrained, or unauthorized personnel. The following Individual Protection Devices are necessary to perform the task being examined: Before proceeding with the installation, a project of the refrigeration system must have been developed, which defines: all the components of the refrigeration system (e.g. -
Page 13: Ceiling Mount
Connect a previously bent pipe onto the inlet of the thermostatic valve (Figure 2-A). .The pipe will exit from the evaporator through the pre-arranged hole or open slots and will then be connected to the liquid piping of the refrigeration system. Seal back the cover and tighten the screws. - Page 14 Figure 5 – Ceiling mount . RCMRØ350, RCMR145__/ED and RCMR245__/ED FIGURE A FIGURE B DETAIL A ATTENTION: on heavier units, it is preferable to perform the ceiling mount without the drainage basin. In these cases, disassemble the basin right after having pulled out the unit from the box, and reposition it only after having fastened the unit to the ceiling.
-
Page 15: Refrigeration Connection
Figure 8 – Ceiling mount RCMR345__/ED and RCMR445__/ED. 4.3.3 Refrigeration connection On the evaporator outlet (pipe at the bottom), you must insert a syphon (Figure 2), which will be connected to the suction pipe of the refrigeration system. Connect the pipe that was previously connected to the inlet of the thermostatic valve (Figure 2-A) to the liquid piping of the refrigeration system. - Page 16 Figure 9– Terminal boards in the shunt box. insert a spindle on the specific opening (near the middle of the terminal board); the blade of the spindle keeps the spring open, allowing the operator to introduce the conductor; insert the conductor with the end peeled off or equipped with a crimped terminal; pull out the spindle.
- Page 17 Figure 11 – Wiring diagram RCMR Ø350 with defrosting heaters powered with 230V/1Ph/50-60Hz. 1 1 2 3 N N N 4 N 7 5 230V/1Ph/50-60Hz 230V/1Ph/50-60Hz 230V/1Ph/50-60Hz ATTENTION: the defrost heaters are only included in the ED version (version with electrical defrost Figure 10-11 see R1, R2 ,R3, and R4).The drainage heater is supplied as optional (Figure 10- 11 see R5) To make the wires pass, use the side openings that are already arranged.
- Page 18 Figure 13 – Wiring diagram RCMR Ø450 with defrosting heaters powered with 230V/1Ph/50-60Hz. 12 3 NN4N5 230V/1Ph/50-60Hz 230V/1Ph/50-60Hz 230V/1Ph/50-60Hz ATTENTION: the defrost heaters are only included in the ED version (version with electrical defrost Figure 12-13 see R1, R2 ,R3, R4, R5 and R6).The drainage heater is supplied as optional (Figure 12- 13 see R7) To make the wires pass, use the side openings that are already arranged.
- Page 19 4.4 Storage In case it were necessary to store the for a certain time before installing it, we recommend that you protect PARTLY COMPLETED MACHINERY it adequately and store it in a suitable environment, one having the following characteristics: outer surfaces resistant to atmospheric agents; protected against access of unauthorized persons;...
-
Page 20: Maintenance And Cleaning
DANGER : only disassemble the parts of the that are actually necessary to perform PARTLY COMPLETED MACHINERY the specific maintenance operation. All the materials with an environmental impact which need to be eliminated following maintenance interventions must be disposed of in accordance with the norms in force. ATTENTION: to dispose of materials with a high environmental impact, if necessary, contact specialized waste collection centers. -
Page 21: Demolition And Disposal
Referring to Paragraph 4.5 – Dis-installation in Chapter 4 - Transport and Installation, proceed to dis-install the PARTLY COMPLETED ; moreover, contact the Technical Offices of the Manufacturer to obtain the necessary assistance during this MACHINERY intervention. To proceed to handle the , operate in accordance with the instructions reported in Paragraph 4.2 - PARTLY COMPLETED MACHINERY Transport and Handling in Chapter 4 - Transport and Installation. - Page 22 The diagram for the removal of the panels and the drawings with the technical and constructional characteristics of the range of RCMR Ø350 and Ø450 air-cooled evaporators are depicted below 8.1 Diagram for removal of panels and motors The diagram for the removal of the panels and of the fan motors is depicted below (Figure 14 and Figure 15). Based on the model chosen, the number and shape of the panels may incur variations.
- Page 23 Figure 15 – Diagram for removal of panels RCMR Ø450. Fixing brackets Electrical connection Terminal box side panel Housing Defrosting heaters Screw for the grounding of the coil Piping side panel Condensate water Drip tray drain connection ATTENTION: the defrost heaters are only included in the ED version (version with electrical defrost RCMR Pag.
- Page 24 Caratteristiche tecniche e costruttive RCMR Ø350 Technical and constructional characteristics of the RCMR Ø350 Caractéristiques techniques et constructives RCMR Ø350 Le misure sono espresse in mm Measurement are in mm Le misures sont en mm Dettaglio A Etichetta di riconoscimento Detail A Identifying label Details A...
- Page 25 Si valutino i pesi dei diversi modelli RCMR Ø350 come indicati nelle tabelle successive: Evaluate the weights of the different RCMR Ø350 models, as indicated in the following charts: Evaluer les poids des différents modèles RCMR Ø350 comme indiqués dans les tableaux suivants : Modello RCMR 1350604...
- Page 26 Caratteristiche tecniche e costruttive RCMR Ø450 Technical and constructional characteristics of the RCMR Ø450 Caractéristiques techniques et constructives RCMR Ø450 Le misure sono espresse in mm Measurement are in mm Le misures sont en mm MODELLO MODEL RCMR MODÈLE 1410 1960 2460 2460...
- Page 27 Si valutino i pesi dei diversi modelli RCMR Ø450 come indicati nelle tabelle successive: Evaluate the weights of the different RCMR Ø450 models, as indicated in the following charts: Evaluer les poids des différents modèles RCMR Ø450 comme indiqués dans les tableaux suivants : Modello RCMR 1450804...
- Page 28 S.r.l. - Costruzione Gruppi Frigoriferi e Accessori Via Sicilia, 7 - 61022 Fraz. Montecchio VALLEFOGLIA (PU) - Italy - Tel. +39 0721 919911- Fax +39 0721 490015 www.rivacold.com - info@rivacold.com...
