- Page 1 Operating Instructions and Parts Manual Air/Hydraulic 22-Ton Service Jack Model JASJ-22C WMH TOOL GROUP 2420 Vantage Drive Elgin, Illinois 60123 Part No. M-454200C Ph.: 800-274-6848 Revision A 9/05 www.wmhtoolgroup.com Copyright © WMH Tool Group...
-
Page 2: Warranty And Service
Warranty and Service WMH Tool Group warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can provide quick service or information. -
Page 3: Table Of Contents
Table of Contents Warranty and Service ..........................2 Table of Contents ............................3 Warning..............................3 Introduction..............................4 Specifications ............................4 Assembly..............................5 Before Operation .............................5 Operation..............................5 Lowering..............................5 Maintenance............................6 Replacement Parts ..........................6 JASJ-22C Service Jack..........................7 Warning 1. Read and understand the entire owner’s manual before attempting assembly or operation. 2. -
Page 4: Introduction
If there are any questions or comments, please contact either your local supplier or WMH Tool Group. WMH Tool Group can also be reached at our web site: www.wmhtoolgroup.com. -
Page 5: Assembly
1. Inspect before use. Do not use if broken, cracked or damaged in any way. Assembly 2. Position handle most convenient NOTE: Part numbers in parentheses refer to operating position. Release handle lock by numbers in the parts breakdown on page 7. pulling positioning lever. -
Page 6: Maintenance
Changing the Oil: Maintenance 1. Lower the ram to the lowest position. • 2. Remove filler plug (96). Keep oil reservoir filled. • 3. Tilt jack on its side and drain the fluid into a Clean the jack after use. suitable container. -
Page 7: Jasj-22C Service Jack
JASJ-22C Service Jack... - Page 8 Parts List: JASJ-22C Service Jack Index No. Part No. Description Size 1....JASJ22C-1....Copper Washer ..................1 2....AHJ12-1....Pump Cylinder ..................1 3....AHJ12-2....Y-Seal* ............5.8x12x5.2mm ....1 4....AHJ12-3....Nylon Gasket*..........5.8x12x1.25mm ....1 5....AHJ12-4....Copper Washer ..................1 6....AHJ12-5....
- Page 9 58 .....TS-1550061 .... Flat Washer ..........M8 ........4 59 .....JASJ22C-59.... Adapter............Ø 48x20mm ...... 1 60 .....JASJ22C-60.... Adapter............Ø 48x50mm ...... 1 61 .....JASJ22C-61.... Adapter............Ø 48x100mm ....1 62 .....JASJ22C-62.... Handle Socket ..................1 63 .....JASJ22C-63.... Handle Socket Bolt ................1 64 .....JASJ22C-64....
