- Page 1 Copyright© Uniphy BV 1996-97 Phyaction® is a registered trademark of Uniphy BV Art. Code 93001212.6 Phyaction is manufactured in The Netherlands by Uniphy BV P.O.Box 558 , NL-5600 AN Eindhoven, the Netherlands Tel. +31 499 491800 Fax. +31 499 474734...
-
Page 2: Table Of Contents
Exchanging the ultrasound module..................17 Exchanging the LCD ......................... 18 Exchanging the keyboard PCB (194X)..................18 APPENDIX 1 CIRCUIT DIAGRAMS APPENDIX 2 TUNING THE ULTRASOUND TREATMENT HEADS APPENDIX 3 ERROR LIST Table of contents - Service information Phyaction 190 / 190i... -
Page 3: Chapter 1 General Information
CHAPTER 1 Introduction The Phyaction 190 is an appliance for ultrasound therapy and it can be used for combination therapy with an external electrotherapy appliance. In this chapter the important features from the users manual for service personnel are listed. In the next chapter the theory of operation will be explained. -
Page 4: Installation
1.3.5 Fitting the head holder As standard, a head holder is supplied with each treatment head. Before you use the Phyaction 190 for the first time, we advise you to fix the head holder(s) to the appliance. The ultrasound treatment head can be connected to the appliance easily and in a user-friendly manner into the head holder. - Page 5 The display indicates which format of treatment head has been selected at that moment. As soon as the Phyaction 190 is switched on using the mains switch or from the stand-by position, or as soon as a treatment 1. GENERAL INFORMATION...
-
Page 6: Technical Specifications
THE ULTRASOUND TREATMENT HEADS, the tuning process is described. 1.4.9 Head holder For each Phyaction 190 a head holder for each treatment head is supplied as standard. You can fit this to the appliance easily yourself. For a description of fixing the head holder to the appliance please refer to the drawing which is enclosed in the packing for the head holder. -
Page 7: Chapter 2 Theory Of Operation
General block diagram The block diagram of the Phyaction 190 is shown in figure 2.1. The microcontroller core, shown in the middle of the diagram, controls the complete apparatus. The user can set most of the parameters with the keyboard, which is shown at the left of the microcontroller. -
Page 8: Ultrasound Unit
Keeping track of the treatment time is also done by the microcontroller. 2. THEORY OF OPERATION Service information Phyaction 190 / 190i - Page 6... - Page 9 If the output voltage is too high (because of a hardware failure), the microcontroller will shut down the ultrasound unit and give an error message. 2. THEORY OF OPERATION Service information Phyaction 190 / 190i - Page 7...
- Page 10 A resistor is in the connector of the treatment head to enable the microcontroller to detect whether a head is connected and to recognize the type of head that is connected. 2. THEORY OF OPERATION Service information Phyaction 190 / 190i - Page 8...
-
Page 11: Chapter 3 Performance Check
Patient leakage current Also register the measured values in the device records and compare them with the values measured in the past to alert for a possible potentially dangerous tendency. 3. PERFORMANCE CHECK Service information Phyaction 190 / 190i - Page 9... -
Page 12: Iec 601-1 Safety Tests
As soon as you hear the buzzer you should release the keys. If you did it right, you will see at the bottom of the start-up screen that the Phyaction 190 is in service mode. You can now enter the service menu by holding down the yellow key for about 3 seconds. - Page 13 (see section 1.3.6 Checking the ultrasound heads or Appendix 2 TUNING THE ULTRASOUND TREATMENT HEADS). If all of these things are checked and meet the specifications, then the treatment head is probably defective and should be exchanged. 3. PERFORMANCE CHECK Service information Phyaction 190 / 190i - Page 11...
-
Page 14: Chapter 4 Trouble Shooting
Introduction If a Phyaction 190 is defective, in most cases the unit will detect an error in the automatic self test. A full description of this test will therefore help the service technician in finding the error. In the next paragraph you will find this description. - Page 15 The serial (RS-232) interface is initialized and tested. ERROR 27 is generated if a time out occurs. Timer 2 is initialized and tested. ERROR 09 with Value 02 is generated on a time out. 5. TROUBLE SHOOTING Service information Phyaction 190 / 190i - Page 13...
- Page 16 ERROR 11 is generated, with Value the address of the not responding device. 6) Every time the LCD display is accessed it has to respond within a certain time. Otherwise ERROR 21 is 5. TROUBLE SHOOTING Service information Phyaction 190 / 190i - Page 14...
-
Page 17: Description Of The Service Software
As soon as you hear the buzzer you should release the keys. If you did it right, you will see at the bottom of the start-up screen that the Phyaction 190 is in service mode. You can now enter the service menu by holding down the yellow key for about 3 seconds. -
Page 18: Error Messages
(if possible) and sent to the serial port (if possible). Should the microcontroller not be able to show the number on the display, an acoustic signal is given. The list is in Appendix 3. 5. TROUBLE SHOOTING Service information Phyaction 190 / 190i - Page 16... -
Page 19: Chapter 5 Exchanging Boards And Modules
If you place the module you should make sure the LEDs are positioned in the LED-lenses. Before you fix the module with the screws you should lift the appliance to make sure the O-rings are still on their place. 6. EXCHANGING BOARDS AND MODULES Service information Phyaction 190 / 190i - Page 17... -
Page 20: Exchanging The Lcd
Because the memory is on this PCB, you have to realise the patient memory and all data of the treatment heads are erased. This means you have to reinstall the treatment heads (see Appendix 6. EXCHANGING BOARDS AND MODULES Service information Phyaction 190 / 190i - Page 18... - Page 39 Ultrasound treatment head installation procedure Valid from SW-version 3.01 In order to tune a treatment head to the Phyaction 190, it is necessary to take the following steps: Turn off the Phyaction 190 Connect the treatment head you wish to tune...
- Page 40 Figure 12 18) Turn off the Phyaction 190 (but remember, not before the service menu has appeared) 19) Turn on the Phyaction 190 and check the contact control of the head(s) you have just tuned (see the Instructions for use).
- Page 41 Error head or unknown head found at start-up err_VIsns Isns too high during no ultrasound Phase locked loop: err_PLL_Lock PLL out of lock Internal temperature: err_VTemp Internal temperature too high Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 1 /...
- Page 42 Incorrect checksum in the first 32 Value contains the kByte of the EPROM. Check the LSB of the 16 bit EPROM contents and the checksum Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 2 /...
- Page 43 Check the complete I²C bus and the error occurs. Value microcontroller if Value=40 (the contains the address of the device that first device accessed). caused the time out. Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 3 /...
- Page 44 (Mask for detecting a keyboard error). Value contains the err_KeyPressed A key action is detected during number of the detec- power up. Thi f Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 4 /...
- Page 45 The reference voltage is outside its Value is the (8-bit) limits ( < 2.39V = 79h or measured voltage of > 2.63V = 86h). Vref. Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 5 /...
- Page 46 The software has found an abnormal end of program flow. Check the software. Check the EPROM and data/address lines. Check the microcontroller. Auteur: W. Thijssen Paraaf: File: C:\WINDOWS\Temporary Internet Uniphy B.V. Files\OLK1242\EL190001.DOC Versie: 1.1 Datum: Pagina: 6 /...
