Summary of Contents for Odom ES3
- Page 1 Odom ES3 Setup Click to edit Master title style ES3 Hardware Configuration • Click to edit Master text styles – Second level • Third level – Fourth level » Fifth level Slide 1 odomhydrographic.com, USA, 225.769.3051...
- Page 2 Note the reading which is at the same • Click to edit Master text styles depth as the ES3 head. Input that number into the ES3 control software. – Second level Using the Digibar software upload and store the cast on the Hysweep computer.
- Page 3 Odom ES3 Setup Digibar V Click to edit Master title style The Digibar V was designed from the beginning to provide accurate and timely velocity information to your multibeam system or other acoustic • Click to edit Master text styles instrument where knowledge of the speed of sound in water is required.
- Page 4 Ethernet cables and software. * Important Note: A computer is required for the software that is supplied with the ES3. This computer is in addition to the computer required for the data acquisition computer. Only the software required by the ES3 should run on this computer during data acquisition.
- Page 5 VDC nominal (9 to 30 VDC range with J-Box) Dimensions: 193mm (7.86”) L, x 162mm (6.38) H, x 92mm (3.63) W, Weight: 4kg (10lb) in air, Material: Stainless Steel, Power/Data Interface J-Box: Three (3) port Ethernet switch (ES3, Data Acquisition PC, and spare) Slide 5...
- Page 6 Odom ES3 Setup Click to edit Master title style • Click to edit Master text styles – Second level • Third level – Fourth level » Fifth level Slide 6 odomhydrographic.com, USA, 225.769.3051...
- Page 7 • Click to edit Master text styles – Second level Transducer • Third level Power ON / OFF switch – Fourth level » Fifth level Back Spare Ethernet Ethernet to Hypack External Trigger Ethernet to ES3 Software Slide 7 odomhydrographic.com, USA, 225.769.3051...
-
Page 8: Second Level
Heading – Second level Odom Junction Box Ethernet Interface • Third level – Fourth level » Fifth level ES3 Transducer ES3 Power Data Interface ES3 Laptop containing Control Software Ethernet Interface Data from Digibar V Slide 8 odomhydrographic.com, USA, 225.769.3051... - Page 9 Odom ES3 Setup Click to edit Master title style Setup of compact system • Click to edit Master text styles – Second level • Third level – Fourth level » Fifth level Slide 9 odomhydrographic.com, USA, 225.769.3051...
- Page 10 Odom ES3 Setup Click to edit Master title style • Click to edit Master text styles 9 pin connector 9 pin connector Female Front View – Second level Male Front View • Third level Serial data communications are made one of two ways DTE or DCE.
- Page 11 Odom ES3 Setup Click to edit Master title style Basic information concerning Ethernet cables • Click to edit Master text styles – Second level • Third level •A straight-thru cable has identical ends. – Fourth level •A crossover cable has different ends.
- Page 12 The ES3 Power/Data Interface is powered by it’s own power supply, 24VDC. » Fifth level Data is transmitted to the desktop computer via Ethernet interface. Since the ES3 Power/Data Interface is basically a hub, either a crossover or straight cable can be used.
- Page 13 • Click to edit Master text styles Hypack Hysweep software module (USB Hardlock key required). Interfaces to ES3 Power/Data Interface via Ethernet connection using a crossover cable, part # 2300-0053-0000. – Second level The sonar head needs to run with a static IP (Internet Protocol) address for both head and PC. The IP address of the PC must be set to 192.168.0.X (X can be any number between 3 and 255).
- Page 14 AUX port is extra, not wired and generally never used. – Fourth level GPS OUT (9 pin female connector) port sends data to the computer operating the ES3 Control software. Use a DCE to DTE cable # 2300-0045- 0000. » Fifth level HEADING OUT (9 pin female connector) port sends heading data to the computer operating Hysweep.
- Page 15 Odom ES3 Setup Click to edit Master title style J-Box Part # 3016-0001-0000 (front view) • Click to edit Master text styles – Second level • Third level – Fourth level J-Box was designed and built with one main purpose in mind. HPR sensors need assistance from devices such as DGPS and »...
- Page 16 Cable # 2300-0045-0000 from the computer to the HEADING I/O port on the back of the J-Box is used to operate TSS control software(using TTY software), ES3 Control software and data input to Hysweep •...
- Page 17 Odom ES3 Setup Click to edit Master title style TSS Motion Sensor model DMS wiring configuration. Connector (part # 0400-0029-0000) for Motion Sensor. The Motion Sensor connector is a 12 pin connector. This wiring information applies if you • Click to edit Master text styles have the Blue TSS cable for a TSS HPR sensor.
- Page 18 Odom ES3 Setup Click to edit Master title style TSS Motion Sensor model DMS wiring configuration. Solder side of connector 0400-0029-0000 (not to scale) • Click to edit Master text styles 14-12 – Second level TSS Connection Hookup Odom Connector •...
- Page 19 Odom ES3 Setup Click to edit Master title style Crescent VS110 The Crescent VS110 provides heading and position data. Submeter accuracy provided with Differential options including SBAS (WAAS, EGNOS, etc.) and beacon differential. • Click to edit Master text styles Port A connects to the GPS RX connector on the J-Box.
