- Page 1 MX1144-DGR/B/H GSM SMS ALARM & CONTROLLER USER MANUAL MX1144-DGR-rev1.06-1021 ERBAŞ TEKNOLOJİ www.erbasteknoloji.com Innovative Solutions Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual...
-
Page 2: Battery Life
- Manufacturer does not guarantee battery life of the device operation. LIMITED LIABILITY - The buyer must agree that Reporter devices will reduce the risk of theft, burglary, fire or other dangers and controls remote devices but do not guarantee any operation against such events. - Page 3 1. DESCRIPTION Reporter MX1144 is a user friendly and a reliable device which sends you SMS text messages and calls you in case of input alarm events, restorations, power failure (B versions) & restorations and periodically sends heartbeat messages. It also controls your remote devices via SMS, free phone call and DTMF phone calls.
-
Page 4: Use Cases
All settings and registered admin & user numbers are saved in Reporter’s own memory. So, settings will not be deleted if battery or SIM card is removed. Device will continue with new batteries or new SIM Card with the last saved settings &... -
Page 5: Installation
Point Wall Mount screwing holes (shown below) to the wall Drill the wall from pointed places Insert fixing plugs into the drilled points Screw in the wall mount screws from the screwing points of the device Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual... -
Page 6: Getting Started
Send an SMS to a mobile number for testing Call a mobile phone number for testing After above steps completed, open the screws. And insert SIM card into the device, by pushing it as shown in below figure. Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual... -
Page 7: Device Configuration
Note: Wires should pass into the holes of the bottom cover! Please check Wiring Diagram! If you want to apply external powered lines to the inputs; make sure voltage levels are between +3V and +27V. It is also very important that you need to connect external device’s GND line to Reporter GND terminal. - Page 8 Please decide which numbers to add as Admin and which to add User by the help of below information. Admin numbers are authorized to make configurations, change & delete settings of the device, receive all alert notifications and control device outputs (relays) remotely. Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual...
- Page 9 Record Succeed. Memory Full // record done but now memory is full Record Failed! Memory Full // cannot record because memory is full 5.4. Delete Admin Authorization Admins only Format Password<space>DELA:Number Example 1111 DELA:+901234511111 Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual...
- Page 10 5.7. MOD1/MOD2 Selection (Relay Control by Phone Calls) To control Relay Outputs by Phone Calls; Reporter has two different mode options. Only one of them has to be selected. As factory default, MOD1 is selected: MOD1 is only used to trigger RLY1 in a predefined period (default: 2 seconds). When you call device;...
- Page 11 Low delays to i.e. 60 seconds. Thus, it will not trigger unnecessary alerts and create the alert in case it left open for at least 1 minute. Reporter allows you to set these delays on each input individually. Also, low-to-high and high-to-low events could be set individually as well.
- Page 12 // format is wrong 6. CHECK DEVICE STATUS (STATUS QUERY) Anytime, while device is external powered, you may send a Status Query SMS to Reporter. It will reply to you with detailed current I/O status, some settings and GSM signal level information.
- Page 13 // turns on RLY1 1#2#3*4# // turns on RLY1,2,4 and turns off RLY3 // turns on all relays // turns off all relays You will hear two beeps if your command is executed successfully. Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual...
-
Page 14: Troubleshooting
LTE/4G/5G during MOD2 dial On MOD2; I can turn on/off relays but I don’t hear beeps - or try dialling *#*#86583#*#* - If above does not help contact your during the execution GSM network operator Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual... -
Page 15: Technical Specifications
170 x 120 x 55 mm IP Water & Dust • IP67 Protection • 1 x MX1144-DGR/B/H GSM Alarm & Controller Device Package Content • 1 x User Manual • 4 x Fixing Screws & Fixing Plugs Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual... - Page 16 10. NOTES Device Phone Number Admin Numbers User Numbers Made in Türkiye Erbas Teknoloji - Reporter MX1144-DGR/B/H User Manual...
