Summary of Contents for POSEIDON PRSH1196
- Page 1 Form – PMPRSH1196 - 001 Poseidon Wireman & Rescue Swimmers Harness PRSH1196 & PRSH1196(LP) User's Manual – Leaders in Aviation and Maritime Life Support Products...
-
Page 2: Table Of Contents
Poseidon NZ. Poseidon® (registered Trademark) Poseidon Wireman/Rescue Swimmers Harness PRSH1196 & PRSH1196(LP) Owner’s Manual Part No. PMPRSH1196-1 Product Warning – Read Manual prior to use: Contents... -
Page 3: Levels Of Caution
ANZS1891.1 approved harness, incorporating dynamic movement, with a controlled snug fit to the body. The PRSH1196 is designed to be integrated to the Poseidon Life Jacket system via the modular design and weeing attachment points, where once integrated the design becomes the PRSH1196(LP) {Life Preserver}. -
Page 4: General Precautions & Warnings
Form – PMPRSH1196 - 001 General Pre-Cautions and Warnings. Poseidon recommends that these instructions are read in conjunction with AS/NZS 1891.4:2009 “Industrial fall- arrest systems and devices”. The PRSH1196 & PRSH1196(LP) is an Integrated harness design and is not allowed to be altered,... - Page 5 Form – PMPRSH1196 - 001 Intended Use: The Wireman/Rescue Swimmers Harness may be used for: Hoisting of Front Rings joined together, or Rear Dorsal attachment limitations: The harness is only permitted to be used where the maximum allowable free fall distance is less than 2 meters All fall arrest connection points are labeled.
- Page 6 Form – PMPRSH1196 - 001 Only competent users who have received training should use this equipment. (Refer to the AS/NZS 1891-4: 2009 recommendations concerning selection, use and maintenance.) Personal energy absorbers that absorb energy by permanent deformation or destructive action must be discarded if that process has commenced.
-
Page 7: Sizing
Large/XLarge Donning the PRSH1196 & PRSH1196(LP) PRSH1196 & PRSH1196(LP) Rescue Swimmers Harness/Life Preserver Donning Process The device is donned like a typical Fall Arrest/Restraint Harness. The device is secured by 3 side-release buckles: one at the waist and one at each thigh. After these buckles have been fastened, there are 5 adjustment points on the harness system to assure proper fit, both right and left for each: waist adjustment, chest adjustment, and thigh adjustment. - Page 8 Form – PMPRSH1196 - 001 Figure 33a - 33h Step a. – Step i. Donning Process Remove harness from packaging and read instructions. Pick up harness by the back “D” ring and shake it so all the straps fall into place. If any of the leg or chest straps are buckled up, un- buckle them to release the straps.
-
Page 9: Adjusting Of Harness
Form – PMPRSH1196 - 001 Adjustment of Harness Figure i Step a. Fasten Buckles a. To fasten buckles such as leg straps and waist belts, snap the Male and Female 3 release buckles together. Make sure the webbing is not twisted and the two buckles are flush against each other when closed. - Page 10 Form – PMPRSH1196 - 001 Figure i Step d. Buckle Keeper d. Slide the keeper away from the buckle to give some slack in the webbing, tilt the buckle and pull the webbing through. Figure i Webbing Flat Must Lay Flat e.
-
Page 11: Drawing / Part Identification
Drawing – Part Identification: Shoulder Adjustments Dorsal rear Hoisting/Fall Arrest D Ring Chest Strap - Adjustable Left Loop Hoist fitting Right Loop Hoist fitting Adjustment Buckles for Girth Adjustment Buckles for Girth Accessory Kit attachment webbings Instruction – Inspection Record Right Side Right Side Release Buckle... - Page 12 Hydration Pak Tube retainer Hydration Hydration attachment attachment webbings webbings Left Ring for Left Ring for Line Line attachment attachment – not Fall – not Fall Arrest Arrest Comfort Pads - adjustable – Leaders in Aviation and Maritime Life Support Products...
- Page 13 Life Jacket Life Jacket attachment attachment webbing webbing – Leaders in Aviation and Maritime Life Support Products...
-
Page 14: Maintenance & Care Of Poseidon Products
Hang to dry the Harness in a well-ventilated area, which is free from direct sunlight. iii. To avoid mildew, hang dry the POSEIDON Harness after every use, and be sure not to stow the product away while damp. Treatment After Immersion... -
Page 15: Service Life
POSEIDON Harness may remain in service if properly maintained and all test and inspection results are satisfactory. Poseidon Harnesses must be inspected before each use by the user and regularly inspected by a competent person and recorded on a register. If the equipment has been involved in a free fall or fails any of the general inspection criteria it must be removed from service and destroyed. -
Page 16: Storage
Qualified repair personnel can perform some repairs, with adequate OEM Approved facilities. The manufacturer should do all major repairs, unless otherwise authorized by Poseidon NZ. This section provides some information to assist with minor or emergency repairs to the POSEIDON Harness and related components. - Page 17 The maintenance recorded has been carried out in accordance with the requirements of Aviation Rule Part 43 and in respect of that maintenance the component is released to service: Note: "Component" being Poseidon NZ made Victim Harness. – Leaders in Aviation and Maritime Life Support Products...
