Vector SL3WAKV Instruction Manual

ULTRABRIGHT LED
SPOTLIGHT
INSTRUCTION MANUAL
1
3
2
7
8
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
© 2020 Baccus Global LLC
Boca Raton, FL 33487
(877) 571–2391
SAFETY GUIDELINES /
DEFINITIONS
DANGER:
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:
Used without the safety alert symbol indicates potentially hazardous situation which, if not avoided, may
result in property damage.
RISK OF UNSAFE OPERATION.
When using tools or equipment, basic safety precautions should always be
followed to reduce the risk of personal injury. Improper operation, maintenance or modification of tools or equipment
could result in serious injury and property damage. There are certain applications for which tools and equipment are
designed. Manufacturer strongly recommends that this product NOT be modified and/or used for any application other
than for which it was designed. Read and understand all warnings and operating instructions before using any tool or
equipment.
READ ALL INSTRUCTIONS
WARNING:
Read all instructions before operating power station. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SL3WAKV_ManualENSP_120120.indd 2 SL3WAKV_ManualENSP_120120.indd 2
IMPORTANT SAFETY
INSTRUCTIONS
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
WARNING –
Risk of fire, electric shock, burst hazard, or injury to persons – when using electrical
appliances, basic precautions should always be followed, including the following:
• The 3W LED gets HOT quickly!
• Only contact trigger when turning on.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Do not operate the light with a missing or damaged lens or enclosure.
• To reduce the risk of injury, close supervision is necessary when the light is used near children.
• Use only attachments recommended or sold by the manufacturer.
4
• Store idle appliances indoors. When not in use, appliances should be stored indoors in dry and high or locked-up places
– out of reach of children.
WARNING –
Fire hazard:
• Never contact combustible material to the lens.
5 • Keep the light lamp away from materials that may burn.
CAUTION –
To reduce the risk of injury or property damage:
• All lights give off heat:
– Do not touch lens while operating.
– Keep combustibles away from light lens. Extreme heat can cause fires.
– Never place the light face down on any surface when lit or not in use. Never store the light face down on any
surface.
• Never look directly into the light or shine the light into another person's eyes. Serious eye injury could occur.
• Keep sharp objects away from lens – it can crack or break.
• Do not expose this unit to extremely high temperatures.
6
• Do not drop or throw light. It contains alkaline batteries.
• Do not disassemble the main body of the unit. Other than the 4 AA size alkaline batteries, there are no user-replaceable
parts.
ALKALINE BATTERY SAFETY INSTRUCTIONS
WARNING
– Batteries can explode, or leak, and can cause injury or fire. To reduce this risk:
• Use only AA alkaline dry cell batteries in this unit.
• Carefully follow all instructions and warnings on the battery label and package.
• Always insert batteries correctly with regard to polarity (+ and –), marked on the battery and the equipment.
• Do not short battery terminals.
• Do not charge batteries.
• Do not mix old and new; or alkaline, standard (carbon-zinc) and rechargeable (nickel cadmium or nickel metal hydride)
batteries. Replace all of them at the same time with new batteries of the same brand and type.
• Remove dead batteries immediately and dispose of per local codes.
• Do not dispose of batteries in fire.
• Keep batteries out of reach of children.
SL3WAKV
• Remove batteries if the device will not be used for several months.
"Transporting batteries can possibly cause fires if the battery terminals inadvertently come in contact with conductive
9
materials such as keys, coins, hand tools and the like. The US Department of Transportation Hazardous Material
Regulations (HMR) actually prohibits transporting batteries in commerce or on airplanes (i.e. packed in suitcases and
BC
carryon luggage) UNLESS they are properly protected from short circuits. So when transporting individual batteries,
make sure that the battery terminals are protected and well insulated from materials that could contact them and cause
a short circuit."
SAVE THESE INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your new Vector
the instructions carefully before using your new Spotlight.
FEATURES
1. 3 Watt LED bulb
2. Rubber Bezel
3. On/Off Trigger
4. Low Battery Voltage LED Indicator
5. End Cap
6. Pistol Grip Handle
POWER SUPPLY
The unit is powered by four AA alkaline dry cell batteries (may be sold separately). You must install the batteries
(following the directions in the next paragraph) before first use and whenever the Low Battery Voltage LED Indicator
flashes red to indicate that battery power is low.
Unscrew the end cap on the back of the unit (counter-clockwise) and remove it. Insert batteries as described in
compartment, observing the warnings and cautions in the "Alkaline Battery Safety Instructions" section. Replace the
end cap on the unit by first aligning the two grooves of end cap to fit over the two ribs in the battery compartment; then
screwing the end cap in a clockwise direction to secure. Do NOT overtighten.
Ultrabright LED Spotlight. Read this Instruction Manual and follow
®
7. Battery Compartment containing four AA alkaline dry
cell batteries (may be sold separately)
8. Ribs (align and fit into the two corresponding grooves
in the end cap)
9. End Cap detail showing grooves
OPERATING INSTRUCTIONS
The On/Off Trigger turns the unit on and off, and is also used to choose the high or low brightness setting.
• Press the On/Off Trigger once to use the spotlight in its high (brightest) setting.
• Press the On/Off Trigger again within 5 seconds to use the spotlight in its low (dimmest) setting.
or
• Press the On/Off Trigger a third time to turn the unit off.
• Press the On/Off Trigger once to use the spotlight in its high (brightest) setting.
• Press the On/Off Trigger again after 5 seconds to turn the unit off.
Notes:
If the spotlight has shut down after extensive operation on its high (brightest) setting, the unit may still be used for a short period, but will only
automatically operate on its low (dimmer) setting by pressing on the On/Off Trigger again.
When used in extremely cold temperatures, the spotlight may shut down even though the batteries are not discharged. Turn off the spotlight and
allow it to warm up for a few minutes before continuing use.
CARE AND MAINTENANCE
Gently clean the outer surfaces of the closed body casing with a soft cloth. Do not immerse the unit in water.
Except for the batteries, there are no user-serviceable parts inside. Contact the manufacturer if any components have
become worn or broken.
Refer to the Safety Warnings in the front of this Instruction Manual when selecting and replacing batteries. Always
dispose of used batteries properly.
DANGER –
To reduce the risk of explosion:
• Do not dispose of batteries in fire as this may result in an explosion.
• Do not expose the unit containing batteries to fire or intense heat as it may explode.
TROUBLESHOOTING
Light will not operate
• The End Cap may be loose. Screw the End Cap clockwise to secure. Do not over-tighten.
• The batteries may be completely discharged. Replace the batteries following the directions given in this manual.
• The light may shut down when used in extremely cold temperatures. Turn off the light and allow it to warm up for a few
minutes before continuing use.
If the light does not operate in normal operating temperatures after replacing the batteries, contact the manufacturer at
1-877-571-2391.
ACCESSORIES
Recommended accessories for use with this unit may be available from the manufacturer. If you need assistance
regarding accessories, please contact manufacturer at 1-877-571-2391.
WARNING:
The use of any accessory not recommended for use with this appliance could be hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts, contact the manufacturer at
1-877-571-2391.
FULL ONE-YEAR WARRANTY
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1) YEAR from
the date of retail purchase by the original end-user purchaser ("Warranty Period").
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be replaced or
repaired in the following ways: (1) Return the product to the manufacturer for repair or replacement at manufacturer's
option. Proof of purchase may be required by manufacturer. (2) Return the product to the retailer where product was
purchased for an exchange (provided that the store is a participating retailer). Returns to retailer should be made within
the time period of the retailer's return policy for exchanges only (usually 30 to 90 days after the sale). Proof of purchase
may be required. Please check with the retailer for their specific return policy regarding returns that are beyond the time
set for exchanges.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects resulting from normal wear and tear,
accidents; damages sustained during shipping; alterations; unauthorized use or repair; neglect, misuse, abuse; and failure
to follow instructions for care and maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you may have other rights which vary from
state to state or province to province. This product is not intended for commercial use.
Be sure to register your product at https://www.baccusglobal.com/registration to receive important product information,
special promotions and offers, and more.
SPECIFICATIONS
Bulb: 3 watt LED bulb
Power Source: 4 AA alkaline batteries (may be sold separately)
Imported by Baccus Global LLC,
621 NW 53rd St., Suite 450, Boca Raton, FL 33487
www.Baccusglobal.com 1-877-571-2391
RD120120
