Bustec ProDAQ 3411 User Manual

Enhanced adc function card

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

ProDAQ 3411

24-Ch. Enhanced ADC

Function Card

PUBLICATION NUMBER: 3411-XX-UM-0100

Bustec Production, Ltd.

World Aviation Park, Shannon, Co. Clare, Ireland

Tel: +353 (0) 61 707100, FAX: +353 (0) 61 707106

Table of Contents

Summary of Contents for Bustec ProDAQ 3411

Page 1 User Manual ProDAQ 3411 24-Ch. Enhanced ADC Function Card PUBLICATION NUMBER: 3411-XX-UM-0100 Copyright, © 1998-2009, Bustec Production, Ltd. Bustec Production, Ltd. World Aviation Park, Shannon, Co. Clare, Ireland Tel: +353 (0) 61 707100, FAX: +353 (0) 61 707106...
Page 2 Production Ltd, be used, in whole or in part to solicit quotations from a competitive source or used for manufacture by anyone other than Bustec Production Ltd. The information herein has been developed at private expense, and may only be used for...
Page 3: Table Of Contents
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM Table of Contents Introduction _______________________________________________________ 7 Installation ________________________________________________________ 9 2.1. Unpacking and Inspection _______________________________________________ 9 2.2. Reshipment Instructions ________________________________________________ 9 2.3. Preparing the ProDAQ Module ___________________________________________ 10 2.4. Installing a ProDAQ Function Card _______________________________________ 11 2.5.
Page 4 3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual A.1.8 REPCOUNT Register ________________________________________________ 35 A.1.9 PATA Register _____________________________________________________ 35 A.1.10 PATB Register ___________________________________________________ 36 A.1.11 GAIFIL Register __________________________________________________ 36 Appendix C: Specifications ____________________________________________ 37 Copyright, © 1998-2009 Bustec Production Ltd.
Page 5 Figure 6 - Multiple Channel Timing ________________________________________________________ 17 Figure 7 - Function Card Selection ________________________________________________________ 19 Figure 8 - ProDAQ 3411 Soft Front Panel User Interface_______________________________________ 20 Figure 9 - Front End Configuration Dialog __________________________________________________ 20 Figure 10 - Data Acquisition Configuration Dialog ____________________________________________ 21...
Page 6 3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual Reference Documents Title Number ProDAQ 3120 Hardware Manual 3120-XX-HM ProDAQ 3150 Hardware Manual 3150-XX-HM Glossary Analog-to-Digital Converter Open Thermocouple Detection Motherboard Function Card Copyright, © 1998-2009 Bustec Production Ltd. Page 6 of 40...
Page 7: Introduction
25 and 26 channel. The ProDAQ 3411 function card is one of a range of function cards designed to provide full functionality when installed in one of the range of ProDAQ motherboard modules such as the ProDAQ 3120.
Page 9: Installation
2.2. Reshipment Instructions Use the original packing material when returning a ProDAQ module to Bustec Production Ltd. or calibration or servicing. The original shipping carton and the instrument's plastic foam will provide the necessary support for safe reshipment.
Page 10: Preparing The Prodaq Module
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual 2.3. Preparing the ProDAQ Module To install a ProDAQ Function Card into one of the ProDAQ Motherboards, you need to remove the modules top cover: 1 - Module Cover 2 - Cover Screws...
Page 11: Installing A Prodaq Function Card
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM 2.4. Installing a ProDAQ Function Card The ProDAQ Function Cards are arranged inside the ProDAQ Module in four stacks of two cards each. The function cards are mounted face down, e.g. the front-panel connectors as well as the motherboard connectors are underneath the PCB.
Page 12: Figure 2 - The Prodaq Module Assembly
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual 1 - 2.5mm Panhead Screws 2 - 2.5mm Panhead Screws 3 - Module Handle 4 - Ring 5 - Mounting Angle 6 - 2.5mm Panhead Screws 7 - Standoff 8 - Spacer 9 - Crinkle Washer 10 - 2.5mm Panhead Screw...
Page 13: Removing A Prodaq Function Card
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM 2.5. Removing a ProDAQ Function Card Removing a ProDAQ Function Card is exactly the reverse operation then installing it. After removing the top cover and the front panel as described previously, remove the three roundhead screws that fix the function card(s) on the standoffs.
Page 15: Theory Of Operation
0.01% accuracy. 3.2. Programmed Conversion The ProDAQ 3411 allows to separately acquire single samples on one channel at a time. By using the ADCconv registers, the control logic will automatically switch the multiplexer to the requested channel and start the ADC conversion. The result can be read through the ADCvalue register.
Page 16: Multiplexed Conversion
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3.3. Multiplexed Conversion To acquire consecutive samples from multiple input channels, the ProDAQ 3411 features a data acquisition mode where the control logic automatically switches the input multiplexer between the enabled channels and moves the converted values of such a scan into the on-board FIFO. The FIFO logic allows generating asynchronous signals to the application when data is available.
Page 17: Figure 5 - Conversion Timing
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM time Start command Mux select ADC ready ADC start delay time ADC readout settling time conversion time input signal 0.1% 0.01% signal at ADC ChE 2-Apr-1998 Figure 5 - Conversion Timing...
Page 18: The On-Board Fifo
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3.3.4. The on-board FIFO The ProDAQ 3411 features an on-board FIFO to buffer the data generated during data acquisition. The FIFO control logic is able to generate signals when the amount of data in the FIFO reaches a certain level.
Page 19: The Vxiplug&Play Driver
Figure 7 - Function Card Selection If no ProDAQ 3411 is available in your system, the soft front panel application can be run in demo mode, allowing to operate all controls as if connected to a 3411. After initializing the ProDAQ 3411 function card, during which a splash screen is displayed, the soft front panel window will appear (see Figure 8 - ProDAQ 3411 Soft Front Panel User Interface).
Page 20: Configuration
(see 5.2 - Setting Gain and Filter). bu3411_setFEconf() Figure 9 - Front End Configuration Dialog In addation the button “Calibrate” allows you to start the calibration of the ProDAQ 3411 as implemented by the driver function bu3411_calibrate().
Page 21: Data Acquisition
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM Figure 10 - Data Acquisition Configuration Dialog The check boxes in the “Channels” field allow define the channel mask, enabling or disabling a channel for the data acquisition. The other controls allow you to choose the number of scans to collect, the source for the scan clock (“Input Trigger”) and to adjust the acquisition timing.
Page 22: The Graph Controls
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual 4.2.3. The Graph Controls The graph controls below the data display can be used to change the scaling of the display or the precision of the labels shown. They allow you to zoom in and out for a more detailed display. A cursor can be activated selecting a point in the display by using the left mouse button.
Page 23: Programming The Prodaq 3411
3411-XX-UM 5. Programming the ProDAQ 3411 This chapter shows how to program the ProDAQ 3411 function card using the VXIplug&play driver. Complete examples can be found in the “Examples” subdirectory of the driver. All functions are explained in detail in the help file coming with the driver.
Page 24: Setting Gain And Filter
5.2. Setting Gain and Filter The filter and gain stages on the ProDAQ 3411 function card are configured using the function . It takes as arguments the session to the instrument, a value for the gain bu3411_setFEconf() setting, a value for the filter setting and a flag, which switches on or off the OTD (Open Thermocouple Detection).
Page 25: Acquiring A Waveform
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM The channel mask is a 32-bit integer, whose first 26 bits are used to specify whether a channel shall be included in the scan or not. Bit 0 represents channel 1, bit 1 channel 2 and so on. Bit 24 represents channel 25, which is connected internally to Ground, and bit 25 channel 26, which is internally routed to the voltage reference bus from the motherboard.
Page 26: Asynchronous Acquisition
5.5. Asynchronous Acquisition To acquire data continuously, the ProDAQ 3411 needs to be configured for scanning the input channels and moving the data into the on-board FIFO. The FIFO memory stores the data until the host computer is ready to read out the data.
Page 27: Calibration
. If the motherboard housing the bu3411_acquireWaveform() bu3411_readAcquisition() ProDAQ 3411 function card is not equipped with a voltage reference, the function performs only an offset calibration. Copyright, © 1998-2009 Bustec Production Ltd. Page 27 of 40...
Page 29: Appendix A: Front Panel Connector
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM Appendix A: Front Panel Connector The front panel connector used on the ProDAQ 3411 is a 50-pin female SCSI with the following pin-out: Signal Pin # Signal Trigger out Trigger in...
Page 31: Appendix B: Register Description
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM Appendix B: Register Description A.1 Address Map All addresses are given in a hexadecimal notation. “FC Address” specifies the address in the internal function card address space of the motherboard. “VXI Offset” is the offset to be used when accessing this register directly via the function card space mapped into the VXI memory space of the motherboard.
Page 32: Detailed Register Description
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual A.2 Detailed Register Description A.1.1 FCID Register The function card ID register contains a unique number used to identify the card. Operation Initial Function Card ID (0xA0D8) Content A.1.2 GCSR Register...
Page 33: Fclen Register
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM A.1.3 FCLEN Register Specifies the FIFO size in words. Operation Initial FIFO size Content 3411-AA: 0x0800 (2048 words) 3411-AB: 0x4000 (16384 words) A.1.4 OTRI Register Register to configure the output trigger.
Page 34: Itri Register
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual A.1.5 ITRI Register Configures the input trigger of the function card. Operation Initial not used FPo Edge FPin SWT MBT DIVC not used Content Writing a one (“1”) to this bit enables the sample clock as specified in the DIVCLK register as DIVC a source for the input trigger.
Page 35: Mode Register
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM A.1.7 MODE Register The function card ID register contains a unique number used to identify the card. Operation Initial FIDC FIDD ADAI FIRS FIEN not used Content Enables the FIFO for pattern capture/generation.
Page 36: Patb Register
3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual A.1.10 PATB Register Defines which channel takes part in the data acquisition. The PATB register helds the mask for channels 17 ...24, 25 (Ground) and 26 (Voltage Reference). Operation Initial not used...
Page 37: Appendix C: Specifications
ProDAQ 3411 24-Ch. ADC Function Card User Manual 3411-XX-UM Appendix C: Specifications Number of Input Channels Differential Input Type ±10 mV to ±10 V Input Voltage Range 1, 10, 100, or 1000 Gain Selection Filter Selection 10 Hz, 100Hz, 1000 Hz or Bypass...
Page 38 3411-XX-UM ProDAQ 3411 24-Ch. ADC Function Card User Manual 0° C to 50° C Operating Temperature Storage Temperature -40° C to 70° C < 30 min. Warm-up Time 121980 Hrs. MTBF VXIplug&play Driver Software Support Copyright, © 1998-2009 Bustec Production Ltd.
Page 40 Bustec Production, Ltd. World Aviation Park, Shannon, Co. Clare, Ireland Tel: +353 (0) 61 707100, FAX: +353 (0) 61 707106 Bustec, Inc. 17820 Englewood Dr #14, Middleburg Hts, OH 44130, U.S.A Tel. +1 440 826 4156, Fax: +1 440 826 4184...
