DIGITAL ALARM COMMUNICATOR TRANSMITTER (DACT) MODULE KIT (P/N 10‐2528)
Important Notices Before You Begin
1. Please read the instructions carefully! Fike products are
used  for  the  protection  of  life  and  critical  assets  and
must  be  installed  and  tested  as  described  in  this
document.
2. Do not use Fike products for any application for which
they are not intended. Fike shall not be in any way liable
for  any  damages  or  losses  incurred  by  you  or  third
parties  arising  from  the  use  of  any  Fike  product  for
which the product is not intended by Fike.
3. Do  not  use  Fike  products  described  in  this  document
outside of the ranges specified by Fike. Fike shall have
no liability for malfunctions or damages arising out of
the use of Fike products beyond such specified ranges.
4. Fike  reserves  the  right  to  change  product  designs  or
specifications without obligation and further notice.
5. This document is subject to the Fike full disclaimer at
http://www.fike.com/disclaimer.
6. Visit  www.fike.com  to  contact  us  or  to  download  the
latest version of this document.
Important Safety Notes
The following formats are used for safety notes in these
instructions.
WARNING
This  type  of  note  is  used  to  indicate  the  presence  of  a
hazard that will or may cause personal injury or death or
loss of service if safety instructions are not followed or if
the hazard is not avoided.

CAUTION
This type of note indicates the presence of a hazard that
will  or  may  cause  damage  to  the  equipment  if  safety
instructions  are  not  followed  or  if  the  hazard  is  not
avoided.

Indicates the message is important, but not of a warning
or caution category. These notes can be of great benefit to
the user and should be read.
Doc. No. 06‐479 ● Rev.3, March 2019

INSTALLATION INSTRUCTIONS
NOTE

Mounting Location
The  DACT  mounting  location  varies  depending  upon  the
control panel enclosure it is to be installed into. The images
below show the appropriate DACT mounting locations for
each compatible control panel enclosure.
IMPORTANT! When installing the DACT in the CyberCat™
50  or  Cheetah™  Xi  50  enclosures,  the  DACT  must  be
installed before the control board.
DACT Mounting for CyberCat™ 50 or Cheetah™ Xi 50
DACT Mounting for CyberCat™ 254/1016 or Cheetah™ Xi

ISO 9001:2015 Certified




Page 1 of 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10-2528 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fike 10-2528

  • Page 1 50  or  Cheetah™  Xi  50  enclosures,  the  DACT  must  be  for  any  damages  or  losses  incurred  by  you  or  third  installed before the control board.  parties  arising  from  the  use  of  any  Fike  product  for  which the product is not intended by Fike.  3. Do  not  use  Fike  products  described  in  this  document ...
  • Page 2: Installation

    To install the DACT into the CyberCat™ 254/1016 or  static  discharge  will  not  occur.    If  the  module  requires  Cheetah™ Xi system enclosures:  repair  or  return  to  Fike,  it  must  be  shipped  in  an  anti‐ static bag.  1. Carefully  unpack  the  DACT  and  check  for  shipping  damage.  The  DACT  is  installed  onto  the  threaded  press  studs ...
  • Page 3     DACT Wiring: CyberCat™ 254/1016 and Cheetah™ Xi     3. Install RS485 wiring from the system controller (terminal  The wiring diagram below shows how to electrically connect  P6) to the DACT (‐ to A; + to B), as shown below.  the DACT into the CyberCat™ and Cheetah™ Xi panels.  1. Install wiring to connect 24VDC continuous power from  4. Connect  incoming  phone  lines  and  test  for  proper  the system controller (Terminal P7, Aux. Output, +/‐) to  operation.  the DACT, as shown below.   NOTE   When the DACT module is installed, the incoming phone  2. Apply 24VDC power to the DACT and program using the  lines  (power‐limited)  must  be  routed  separately  from  10‐2477 five‐zone hand‐held DACT programmer.  any non‐power‐limited relay connections to the system  controller.      DACT Wiring: CyberCat™ 254/1016 and Cheetah Xi™ Doc. No. 06‐479 ●...
  • Page 4   DACT Wiring: CyberCat™ 50 and Cheetah™ Xi 50     3. Install  RS485  wiring  from  the  system  controller  The  wiring  diagram  below  shows  how  to  electrically  connect the DACT into the CyberCat™ 50 and Cheetah™ Xi  (terminal  P6)  to  the  DACT  (‐  to  A;  +  to  B),  as  shown    below.  1. Install wiring to connect 24VDC continuous power from  4. Connect  incoming  phone  lines  and  test  for  proper  operation. ...
  • Page 5: Dact Programming

    Refer  to  Bosch  document  FPT‐DACT  Operation  and  must be added to the control panel’s peripheral device list  Installation  Guide  for  dialer‐specific  options  and  (address  2–32)  and  selected  for  supervision.    This  allows  programming instructions.  The following options must be  trouble with the DACT to be reported to the Fike control  configured  into  the  DACT  for  proper  operation  with  Fike  system and transmitted to the receiving station on one of  control systems:  the phone lines.   System Date and Time  DACT operational functions must be programmed into the ...
