MillRight MEGA V FS Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS FOR THE MILLRIGHT CNC MEGA V FS
Be sure to check the resources page for the most updated assembly instructions.
The resources page has a parts picture guide to further assist you in assembly.
Important safety rules for operating your MillRight CNC Mega V FS:
Never place your hands near a spinning end mill or bit. Keep your hands off the gear rack!
Always wear eye and ear protection while operating your machine.
Always run a dust collector or wear a mask while performing a milling operation.
Do not leave the machine unattended while running a milling operation.
Do not operate your machine while under the influence of alcohol or drugs.
Secure long hair and loose clothing so it is not caught in spinning mechanisms.
Ensure work pieces are properly secured before running a milling operation.
Keep a fire extinguisher nearby.
Visually inspect wires prior to power up to prevent short circuits.
The Mega V FS is a big, heavy machine. Plan on spending a full weekend in assembly and seeking help with moving or
flipping heavy assemblies.
We recommend using a blue thread locker on any fastener not secured with a lock washer or lock nut.
Page 1 of 33
For additional resources, see
Contact
support@millrightcnc.com
We have a big online community. Be sure to join in the discussion.
Facebook MillRight CNC User Group
Facebook MillRight CNC Mega V Group
MillRight CNC Forum at www.millrightcnc.proboards.com
Version 1.02
www.millrightcnc.com/resources
if you have questions.
