Summary of Contents for Arkuz BlueNet Power+
- Page 1 Arkuz BlueNet Power+ Device Installation Guide...
-
Page 2: Table Of Contents
Contents Arkuz BlueNet Power+ Product Contents. Typical Electrical Connections. Connecting Arkuz BlueNet Power+ device to your Electrical Loads. Your connections to Electrical Load powered by Arkuz BlueNet Power+ device. -
Page 3: Arkuz Bluenet Power
Arkuz BlueNet Power Product Content Arkuz BlueNet Timer Module. The BlueNet Power+ module has Wire set 1: 2 wires of 2.5mm gauge for Input Supply GREEN and a wire of 0.75 mm gauge for Earthing. Wire set 2: 2 BLACK wires of 2.5mm gauge for Output Load... -
Page 4: Typical Electrical Connections
Typical Electrical Connections 110/220 Volt AC WALL SOCKET SUPPLY (LINE, NEUTRAL & EARTH). SUPPLY Load is connected to LOAD the switch through a voltage stabiliser... -
Page 5: Connecting Arkuz Bluenet Power+ Device To Your Electrical Loads
Connecting Arkuz BlueNet Power device to your Electrical Loads Items Required Arkuz Smart BlueNet Timer Screw Driver Electric Wire Duct Tape... - Page 6 Electrical Loads The installation deals with High Voltage AC current hence take at most caution while installing the Arkuz BlueNet Power system. It is highly recommended that any electricity coming to the switchboard panel where the smart light...
- Page 7 Connecting Arkuz BlueNet Power device to your Electrical Loads Step 2 WALL SOCKET Disconnect Connections between Volgate Stabiliser SUPPLY and the Load. LOAD In case Voltage stabilizer in not used then the connection between the wall socket and the Load...
- Page 8 Connecting Arkuz BlueNet Power device to your Electrical Loads Step 3 Connect the set of wires of Arkuz BlueNet Power device to the Supply side LINE & NEUTRAL. WALL SOCKET Connect the BLACK wire of Arkuz BlueNet Power device to...
-
Page 9: Your Connections To Electrical
Your connections to Electrical Load powered by Arkuz BlueNet Power device WALL SOCKET SUPPLY LOAD... - Page 10 Arkuz Technologies beyond possibilities...
