CMT106
IDE Controller and Hard Drive
Carrier utilityModule
User's Manual
Hardware Revision 1.0
Publication No. CMT106 8/28/98

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMT106 and is the answer not in the manual?

Questions and answers

Summary of Contents for Real Time Devices CMT106

  • Page 1 CMT106 IDE Controller and Hard Drive Carrier utilityModule User’s Manual Hardware Revision 1.0 Publication No. CMT106 8/28/98...
  • Page 2 CMT106 IDE Controller and Hard Drive Carrier utilityModule User’s Manual REAL TIME DEVICES USA, INC. PO Box 906 200 Innovation Blvd. State College, PA 16804-0906 USA Phone: (814) 234-8087 FAX: (814) 234-5218 E-Mail sales@rtdusa.com techsupport@rtdusa.com Website www.rtdusa.com...
  • Page 3 Notice: We have attempted to verify all information in this manual is correct as of the publication date. Information in this manual may change without prior notice from Real Time Devices USA. Published by Real Time Devices USA, Inc. 200 Innovation Blvd.

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION Features CHAPTER 2 CONFIGURING THE UTILITYMODULE Jumpers CHAPTER 3 INSTALLING THE UTILITYMODULE Recommended Procedure CHAPTER 4 CONNECTING THE UTILITYMODULE PC/104 Bus Connectors, CN1 and CN2 IDE, CN3 CHAPTER 5 USING THE UTILITYMODULE IDE Hard Disk Power Protection Circuitry CHAPTER 6 RETURN POLICY AND WARRANTY Return Policy...

  • Page 5: Chapter 1 Introduction

    This module allows you to stack a 2.1 Gbyte 2.5 inch hard drive in your PC/104 system.. CMT106 IDE and Hard Drive Carrier utilityModule The CMT106 utilityModule was designed to provide an IDE hard drive in the PC/104 stack to support the Real Time Devices family of cpuModules and other standard PC/104 processor modules.
  • Page 6 Features CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 7: Chapter 2 Configuring The Utilitymodule

    • IRQ14(Primary)/IRQ15(Secondary) Default Settings The utilityModule is delivered from the factory configured with JP1 set for Primary and JP2 set for IRQ14. Locations The figure below shows jumper locations. Jumper Locations CMT106 IDE controller utilityModule Real Time Devices USA, Inc.
  • Page 8 Jumpers CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 9: Chapter 3 Installing The Utilitymodule

    CAUTION: Do not force the module onto the stack! Wiggling the module or applying too much force may damage it. If the module does not readily press into place, remove it, check for bent pins or out-of-place keying pins, and try again. CMT106 IDE controller utilityModule Real Time Devices USA, Inc.
  • Page 10 Recommended Procedure CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 11: Chapter 4 Connecting The Utilitymodule

    Locations The figure below shows connector locations. Connector Locations Connectors Connector Function Size PC/104 XT Bus 64 pin PC/104 AT Bus 40 pin IDE Connector 44 pin CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 12: Pc/104 Bus Connectors, Cn1 And Cn2

    +12V IOCHRDY (KEYING PIN) SMEMW* SA19 SMEMR* SA18 IOW* SA17 IOR* SA16 DACK3 SA15 DRQ3 SA14 DACK1* SA13 DRQ1 SA12 REFRESH SA11 SYSCLK SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2* BALE CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 13: Ide, Cn3

    HD data 8 in/out HD data 6 in/out HD data 9 in/out HD data 5 in/out HD10 HD data 10 in/out HD data 4 in/out HD11 HD data 11 in/out CMT106 IDE controller utilityModule Real Time Devices USA, Inc.
  • Page 14 Ground signal Interrupt Request IOCS16* 16 bit transfer Address 1 Ground signal Address 0 Address 2 HCS0* HD Select 0 HCS1* HD Select 1 HDD activity LED (-) Ground signal CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 15: Chapter 5 Using The Utilitymodule

    Chapter 5 IDE Hard Disk The CMT106 provides an IDE interface to 2.5 inch, 2.1 Gbyte harddrive. This harddrive can be set up as the primary or the secondary drive (you must be sure that your CPU bios supports both primary and secondary drives).
  • Page 16 Power Protection Circuitry CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 17: Chapter 6 Return Policy And Warranty

    7) Write the RMA number on the outside of the package. 8) Ship the package to: Real Time Devices 200 Innovation Blvd. State College PA 16803 CMT106 IDE controller utilityModule Real Time Devices USA, Inc.

  • Page 18: Limited Warranty

    REAL TIME DEVICES. This warranty is limited to the original purchaser of product and is not transferable. During the one year warranty period, REAL TIME DEVICES will repair or replace, at its option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to REAL TIME DEVICES.
