For Rojaflex radio awning motors and radio receivers REHK-BI
Eine aktuelle Vollversion der Anleitung finden Sie hier/
You can find a current full version of the manual here/
Vous trouverez ici une version complète et actuelle du mode d'emploi/
Puede encontrar una versión completa actual del manual aquí/
Potete trovare una versione completa attuale del manuale qui/
Een actuele volledige versie van de handleiding vindt u hier/
Aktualną, pełną wersję podręcznika można znaleźć tutaj/
A kézikönyv aktuális, teljes verzióját itt találja:
https://www.rojaflex.com/bedienungsanleitungen.html
ORIGINAL ASSEMBLY AND
OPERATING INSTRUCTIONS
Original Montageanleitung
Original instructions
Mode d'emploi original
Instrucciones originales
Vibration sensor
Rojaflex RVS-01
DE
EN
Originele gebruiksaanwijzing
FR
Oryginalna instrukcja obsługi
ES
Eredeti összeszerelési útmutató
Manuale d'uso originale
IT
NL
PL
HUN
RVS-01_V3- 2022-04-29
Advertisement
Summary of Contents for rojaflex RVS-01
- Page 1 Vibration sensor Rojaflex RVS-01 For Rojaflex radio awning motors and radio receivers REHK-BI ORIGINAL ASSEMBLY AND OPERATING INSTRUCTIONS Eine aktuelle Vollversion der Anleitung finden Sie hier/ Original Montageanleitung Manuale d’uso originale You can find a current full version of the manual here/...
-
Page 2: Table Of Contents
Herewith declares Schoenberger Germany Enterprises GmbH & Co. KG, Hohenschäftlarn, that the radio system type rojaflex sun-wind sensor "RVS-01" complies with the directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.rojaflex.com/konformitaetserklaerungen.html... -
Page 3: General Safety Instructions
/ receiver controlled right. by the sensor as well as the corresponding instructions of the driven sun shading • The sensor must be mounted in such a way that the wind speed can be system! measured without interference! www.rojaflex.com... - Page 4 Never use defective or damaged of their useful life and must not be dispo- equipment. sed of together with normal household waste. • Check the motor controlled by the sensor and the power cable of the motor for integrity. www.rojaflex.com...
- Page 5 This applies in particular to information and telecommunications technology devices such as computers and smartphones. In your own interest, please note that each end user is responsible for deleting the data on the old devices to be disposed of! www.rojaflex.com...
-
Page 6: Function Overview
Function overview The RVS-01 is a battery-powered vibration sensor for motorized awnings. Incoming wind generates vibrations at the drop profile of the awning. The sensor can be set to 9 sensitivity levels and sends a retract command to the previously taught-in receiver when the preset sensitivity level is reached (see technical data for compatible receivers). -
Page 7: Technical Data / Scope Of Delivery
Range approx. 30 m* Channels 1-channel Compatibility Rojaflex radio awning motors (type ELFIM-45M) and receiver REHK-BI Dimensions 150mm x 41mm x 26mm Art. No. 1000018670 * Range data are approximate values and depend on the structural conditions. The sensor must be mounted on the drop profile of the awning. -
Page 8: Programming And Settings
Set the trimmer to level "0" using a small screwdriver. Press key P2 3 times in succession on an already programmed handheld transmitter. Press the P2 key on the RVS-01 once. Motor moves up/down briefly. RVS-01 is programmed. Set the desired sensitivity of the sensor on the trimmer. - Page 9 Notes www.rojaflex.com...
- Page 10 Notes www.rojaflex.com...
-
Page 11: Other Settings And Notes
Notes www.rojaflex.com... - Page 12 Our general terms and conditions apply. Membership number: If you have any questions about this product, please contact us at the following address: rojaflex is a registered trademark of Schoenberger Germany Enterprises GmbH & Co. KG Zechtraße 1-7 82069 Hohenschäftlarn...
