LANSeeker Cable Tester
™
EZ-RJ45
®
The LAN
Seeker is an easy-to-use professional grade data
™
CONNECTORS
cable tester and tone generator. It automatically displays cable
test results using LED indicator lights on the main and the
self-stored remote unit.
When the unit senses a connection between the main and the
remote unit, the battery-saving auto-on feature initiates test
EZ-SNAPJACK ™
results within 2 seconds. The tester automatically powers off
within 5 seconds of the cable being disconnected.
Features:
• Displays cable test results on main and the remote
unit in less than 2 seconds
PoE DETECTOR
split pairs
• Auto-on initiates test when a connection is sensed
between main and remote unit
• Debug mode diagnoses faults one pair at a time
RJ45
• Built-in tone generator
PORTSAVER
• Auto-off to preserve battery power
(9-volt Alkaline battery included)
visit
Applications:
platinumtools.com
to see all of
• Installation and maintenance of twisted-pair
our products
cabling for IP voice, data and IP video
• Troubleshoot failing cables
• Generates tone for tracing wires
