Model: 24GMMR20 (24GHz Pulse radar for vehicle use)
Date:
File name:
Document No.:
All Rights Reserved, Copyright© FURUKAWA AUTOMOTIVE SYSTEMS INC. 2021
User Manual for
24GHz Multi Mode Radar
February 22, 2021
24GMMR20_User Manual_rev3
RA21EX005
Confidential】
【
1
Advertisement
Table of Contents
Summary of Contents for Furukawa 24GMMR20
- Page 1 User Manual for 24GHz Multi Mode Radar Model: 24GMMR20 (24GHz Pulse radar for vehicle use) Date: February 22, 2021 File name: 24GMMR20_User Manual_rev3 Document No.: RA21EX005 Confidential】 All Rights Reserved, Copyright© FURUKAWA AUTOMOTIVE SYSTEMS INC. 2021 【...
- Page 2 ・Multi-mode operation for plural applications ・Automotive interface with warning information and /or target lists Operating temperature：－40℃~＋85℃ Operating voltage：+8V~+16V(typ.12V) ※Vehicular battery power Current consumption：240mA(typ.)＠13.5V ※Depending on operating voltage. Operating frequency ：24.15GHz Confidential】 All Rights Reserved, Copyright© FURUKAWA AUTOMOTIVE SYSTEMS INC. 2021 【...
- Page 3 FCTA function is a function of performing a warning to the driver when the object approaching from the front side satisfy the warning conditions. Detection area Application: Front Cross Traffic Alert Intersection Cross Traffic Alert Confidential】 All Rights Reserved, Copyright© FURUKAWA AUTOMOTIVE SYSTEMS INC. 2021 【...
- Page 4 3.Sensor Components The 24GMMR20 sensor consists of the following components: ・Housing: Plastic ・EMC Shield: ・RF and ECU board: ・Radome: Plastic Figure 1: 24GMMR20 Components FCC ID：2AHE9-24GMMR20 This device complies with part 15 of the FCC Rules. Operation is subject to the following two...
