Summary of Contents for DieselBoss TH4000B
- Page 1 AHD Mobile DVR User Manual TH4000 AHD MOBILE DVR User Manual There are two models available TH4000B INCLUDES GPS NO WI-FI U4000B INCLUDES GPS...
-
Page 2: Table Of Contents
AHD Mobile DVR User Manual Table of Contents Chapter 1 Overview ........................4 Chapter 2 Quick setup ........................4 1．Device Installation ....................... 4 2. User Login ..........................4 3．Setting Time/Date ....................... 5 4. Camera Setup ......................... 5 5. Vehicle Information setup ...................... 6 5.1 DiskManagement ...................... - Page 3 AHD Mobile DVR User Manual 4.1 User Management ...................... 14 4.2 Reverse Camera ......................14 5．Device Maintenance ......................15 5.1 Disk Management ....................... 15 5.2 Alarm Out Setting ....................... 15 6．Alarm settings ........................16 6.1 Input Alarm ......................... 16 6.2 Video Loss ........................17 6.3 Fatigue Driving Alarm ....................
-
Page 4: Chapter 1 Overview
AHD Mobile DVR User Manual TH4000 Chapter 1 Overview The DVR is designed for Analog HD vehicle monitoring. With a high-performance image processing and advanced H.264 video compression technology, the DVR provides an AHD video recording, storage and playback solution. The Device is equipped with a smart power management system and when the voltage of the batteries drops below 11.5V, the device will shut down automatically. -
Page 5: 3．Setting Time/Date
AHD Mobile DVR User Manual Figure 4. Primary Menu 3．Setting Time/ Date Select Basic, then Date/Time. Manually set the time and date, then set TimeSYNC to “no” (otherwise the DVR time/date will change automatically as you travel through different time zones). 4．Camera Setup Select Menu, then Record, then Mode. -
Page 6: Vehicle Information Setup
Truck number and license plate number can be entered to appear on video playback. 5.1 Disk Management Hard drives will typically be formatted by Dieselboss before leaving our warehouse; however, if you are using your own hard drive, it will have to be formatted in the DVR before recording... -
Page 7: Chapter 3 System Menu
AHD Mobile DVR User Manual Chapter 3 System Menu Figure 6. System menu To change from the default view, select either OneView or MultiView and select the viewing mode you want to display. 1.1 Video Playback Playback of recorded video can be done either through the Viewer software, or the DVR menu itself. -
Page 8: Video Backup
AHD Mobile DVR User Manual 1.2 Video Backup Figure 7. Video Backup Used to backup video to a flash drive for easy viewing. You can select “Alarm” to only backup alarm videos, “Normal” to backup any non-alarm videos, or “All” to backup both video types. When selecting what format to export only select ifv if you want video playback to include the GPS position in the DVR Viewer. -
Page 9: Vehicle Information
AHD Mobile DVR User Manual Vehicle Information Preview setting Delay: The system will display the 8-camera view for the time interval you set before switching to the view you set in the mode box. Mode: sets which camera view will display after the delay interval. Preswitch: Switches through the channels at the time interval you set. -
Page 10: Video Output
AHD Mobile DVR User Manual 2.3 Video Output 2.4 On/Off setting On/Off “Ctrl” setting is only used if wiring for ignition power. ACC Delay can set how long the DVR will run after the ignition of the truck is shut off. (must be set in 5 minute intervals). Timing on/ off can be used to set the DVR to run when the ignition is off (start will be the time the DVR will power on at the time you set and the duration can be used to set how long after powering up the DVR will run. -
Page 11: System Setup
Out Format should always be set to NTSC for proper viewing/ recording. If using a high- resolution monitor, resolution can be bumped up to provide a clearer view on the monitor. 2.6 System Information Only used for troubleshooting by Dieselboss. 3．Recording Setup... -
Page 12: Main Stream
AHD Mobile DVR User Manual 3.1 Main Stream This interface shows the current Main Stream setting and the corresponding storage size; you can click any line to set up the corresponding parameters (AV5-8 are available on TH4000 only). In order to change the resolution of the recordings, change the Bitrate from “Fix” to “Variable”, then you will be able to change the quality setting. -
Page 13: Recording Osd (On Screen Display)
AHD Mobile DVR User Manual 3.3 Recording OSD (On Screen Display) You can set up the information you want to be recorded on the selected video channel. 3.4 Image setting Used to change image settings on individual camera channels. (AV5-8 are available on TH4000 only) 3.5 Mirror setting Used to flip camera view horizontally or vertically (for both preview and recording). -
Page 14: 4．Advanced Setting
AHD Mobile DVR User Manual 4. Advanced settings Figure 31: Advanced setting 4.1 User Management You can add/ delete users and modify the login username and privileges. 4.2 Reverse Camera The DVR comes with Reverse camera function which can be configured on any active camera channel. -
Page 15: 5．Device Maintenance
Once you have exported the config from a DVR that is already configured, just click Import, then plug in the flash drive with the config, and the channel names and other settings will be moved over. Restore function should only be used if requested by Dieselboss. -
Page 16: Alarm Out Setting
AHD Mobile DVR User Manual 6. Alarm setting 6.1 Input Alarm Any of the 4 alarm inputs can be set for either positive or negative triggering. The default configuration is shown below. To configure triggering, alarms will have to be enabled (refer to page 7 of the hardware manual for alarm harness pin-out). -
Page 17: Video Loss
AHD Mobile DVR User Manual 6.2 Video Loss Video Loss alarm will be triggered if camera signal is lost on any active channels. 6.3 Fatigue Driving Alarm This function will alert the driver at the time interval you set that it is time to stop driving. 6.4 Over Speed Alarm 6.5 Disk Error If enabled, the DVR will record a special Disk Error event on whichever drive is still readable. -
Page 18: Chapter 4 Installation Warnings
AHD Mobile DVR User Manual Chapter 4 Installation Warnings Make sure to disconnect power when servicing DVR and cameras. Please ensure that the DVR is getting between 8-32V for proper operation. Make sure to plug the red and black wires of the power harness directly into the battery of the vehicle to prevent video noise.
