- Page 1 Indoor Panel Unit with Linux OS Product Manual © 2022 INTERRA Version 1.1...
-
Page 2: Table Of Contents
3.4.1.3. Call Management Center ......................26 3.4.2. Monitor ..............................27 3.4.3. Records ..............................27 3.5. Message ................................28 3.6. Setup ................................... 29 3.6.1. Normal ..............................29 3.6.2. Room ............................... 29 3.6.3. Network ..............................30 3.6.4. Password ..............................31 3.6.5. Version ..............................31 @2022 INTERRA PM2201200174AEN... - Page 3 FITNESS FOR PURPOSE. Interra disclaims all liability arising from this Printed on recycled paper. information and its use. Use of Interra devices in life support and/or safety applications is entirely at the buyer’s risk, and the buyer agrees to defend,...
- Page 4 To obtain the most up-to-date version of this product manual, please visit our Web site at: http://www.interratechnology.com You can determine the version of an Interra document by examining its literature number found on the bottom right corner of any page.
-
Page 5: Content Of The Document
Product Manual 1. Content of The Document This document contains Interra brandmark’s ITR660-0001 & ITR662-0001 Indoor Panel Unit with Linux OS coded devices’ electronics and all essential features information for programming these products. In each subtitle is explained the characteristics of the devices. Modifications of the product and special change requests are only allowed in coordination with product management. -
Page 6: Product Description
Indoor Panel Unit with Linux OS Product Manual 2. Product Description ITR660-0001 & ITR662-0001 are Indoor Panel Units with Linux OS panels that are mainly used for making interacting between the related outdoor intercom units. ITR660-0001 & ITR662-0001 product features are described below : Talkback: Support video call, monitoring, unlocking and checking of call records. -
Page 7: Technical Information
Indoor Panel Unit with Linux OS Product Manual 2.1. Technical Information The following table shows the technical information of the ITR660-0001 & ITR662-0001 Indoor Panel Unit with Linux OS. Product Code ITR660-0001 ITR662-0001 DC 12 V DC 12 V Power Supply... -
Page 8: Connection Diagram & Features
0.4 Nm. Once the device installation is completed, please check the connection and if needed please re-tighten the screws. Fig. 1 : Connection Diagram of ITR660-0001 Indoor Panel Unit Fig. 2 : Connection Diagram of ITR662-0001 Indoor Panel Unit ©2022 INTERRA... - Page 9 During the installation, the camera should be 1450-1550 mm above the ground. The camera tether for photographing the human face should be the top priority. General : Fig. 4 : ITR660-0001 General Look of the Indoor Monitor ©2022 INTERRA PM2201200174AEN...
- Page 10 The following figures show the connectors of the standard version. Fig. 6 : Connectors of the standard version Power: Power input interface connects with 12 V power adapter. The following figure shows the connection diagram. Fig. 7 : Power input connections ©2022 INTERRA PM2201200174AEN...
- Page 11 When the alarm sensor is triggered, the output power is 12 V / 100 mA. Each interface of the alarm zone can be connected with a normally open or normally-closed switch. Fig. 9 : Siren/Alarm interface pin connection ©2022 INTERRA PM2201200174AEN...
-
Page 12: Troubleshooting
• Restart the device to clear any temporary software error. The temperature of the device is too high. • Long-term use leads to high temperature. It is normal and will not affect the device’s useful life and performance. ©2022 INTERRA PM2201200174AEN... -
Page 13: Safety Instructions
Do not touch the device with wet hands. Do not make the power supply slip or cause the impact. Do not use the power supply without the manufacturer’s approval. Do not have the liquids such as water go into the device. ©2022 INTERRA PM2201200174AEN... - Page 14 When the device is not used for a long time, the adaptor and memory card can be removed and placed in a dry environment. When moving, please hand over the manual to new for proper usage of the device. ©2022 INTERRA PM2201200174AEN...
-
Page 15: Homepage
2 bars. These are the Menu bar and Status bar. The status bar includes shortcut keys. The detailed expressions are given in the related subtitles. Fig. 10 : Homepage NUMBER PART NO NAME Menu Bar Status ©2022 INTERRA PM2201200174AEN... -
Page 16: Menu Bar
Menu Bar The menu bar has the Interra logo on the left and the date and time on the right. You can go to 4 different sections from the menu bar. These sections, from left to right, are Security, Intercom, Message and Setup. These sections will be explained as separate subtitles. -
Page 17: Security
5-) SIP Registration Status: This icon keeps lit when SIP is registered. 3.3. Security Clicking the “Security” icon on the main interface, the system will enter the following interface. Security Fig. 13 : Security Interface and its features ©2022 INTERRA PM2201200174AEN... -
Page 18: On/Off
(1) During the delay time of arming, clicking the “OFF” icon, the system will emit a beep. Then the alarm will be stopped. (2) Input user password (the default password is 1234) to stop the alarm under ON status. ©2022 INTERRA PM2201200174AEN... -
Page 19: Camera
3.3.2.1. IP Camera Setting Login to the webpage of the indoor monitor by : Username : user Password : 1234 and then you can access the following webpage : ©2022 INTERRA PM2201200174AEN... -
Page 20: Zone
Remark: It shall be set when the alarm is OFF. Click the “Zone” icon and input a 1-16 digits password (the default password is 1234), the system will enter into the following interface: Fig. 17 : Zone interface of the Indoor Monitor ©2022 INTERRA PM2201200174AEN... -
Page 21: Alarm Type
Clicking the mode setting box will pop up a dialogue box like the following interface. On this interface, you can set the mode as: 3C, NO, NC or BELL. Fig. 19 : Mode page of the zone interface ©2022 INTERRA PM2201200174AEN... -
Page 22: Delay Time
Clicking the input box of sensor type will pop up a dialogue box as shown in the following interface. Each sensor type can be set up as: Smoke, Gas, PIR, Door, Window, Panic and Flood. Fig. 21 : Selection of the Sensor Type ©2022 INTERRA PM2201200174AEN... -
Page 23: Scene
To stop the alarm sound, input the password (the default password is 1234). 3.3.4. Scene Clicking the “Scene” icon, the system will enter into the following interface : Fig. 23 : Scene interface of the Indoor Panel ©2022 INTERRA PM2201200174AEN... -
Page 24: Setup
Clicking the “Setup” icon, the system will enter into the following interface: Fig. 24 : Setup interface of the Indoor Panel You can set the new user password with 1-16 digits (the default password is 1234). User password is used for security. ©2022 INTERRA PM2201200174AEN... -
Page 25: Intercom
Clicking the “Intercom” icon on the main interface, the system will enter into the following interface: Fig. 25 : Intercom interface of the Indoor Panel 3.4.1. Call Out Clicking the “Call Out” icon, the system will enter the following interface: Fig. 26 : Call Out interface of the Indoor Panel ©2022 INTERRA PM2201200174AEN... -
Page 26: Contacts
If the management center cannot be searched or the call failed, the system will call the next management center. When the management center answers, the indoor monitor will ring and stop calling. Click icon to end the communication. ©2022 INTERRA PM2201200174AEN... -
Page 27: Monitor
Click icon to unlock the door. Remark: The system’s default monitoring time is 25s. 3.4.3. Records Clicking the “Records” icon, the system will enter the following interface: Fig. 29 : Records interface of the Indoor Panel ©2022 INTERRA PM2201200174AEN... -
Page 28: Message
Note: Only by installing the management software on a PC which is usually located at the guard center, an indoor monitor receive the message sent by the PC. Click icon to page up; click icon to page down; click icon to delete the record. Up to 64 messages can be received. ©2022 INTERRA PM2201200174AEN... -
Page 29: Setup
You can select the volume, intercom, language, time zone and auto answer that you want. 3.6.2. Room Click the “Room” icon, then input 1-16 digits password (the default password is 123456) to enter into the following interface: Fig. 32 : Room interface of the Indoor Panel ©2022 INTERRA PM2201200174AEN... -
Page 30: Network
Server: If the Central Management System (CMS) is used, the IP of the computer on which the CMS is installed should be entered in this section. Click “OK” to save the settings. This information is entered by authorized persons during system commissioning. Unauthorized persons should never change the relevant settings. ©2022 INTERRA PM2201200174AEN... -
Page 31: Password
You can set the new system password with 1-16 digits (the default password is 123456). System password is used for system settings. 3.6.5. Version Click the “Version” icon to enter into the following interface: Fig. 35 : Version interface of the Indoor Panel You can look over the relevant information. ©2022 INTERRA PM2201200174AEN... - Page 32 Product Manual CONTACT INFORMATION THE INTERRA WEBSITE EUROPE Turkey Interra provides documentatıon support via our web site www.interratechnology.com This website Interra is used as a means to make files and information Cumhuriyet Mah. Kartal Cad. Simkan Plaza No:95/1 easily available to customers. Accessible by using Kartal/İstanbul...
