Neuton Power 12.8V LiFePO4 (LFP) Slimline (SL) Series Battery

User Manual

DOCUMENT NOTICE: The information contained in this manual is the property of YHI Power and is subject to change

without notice. It is the customer's responsibility to satisfy itself as to whether the information contained herein is

adequate and sufficient for a user's particular use. It is the further responsibility of each user to ensure that all

applications of Neuton Power products are appropriate and safe based on conditions anticipated or encountered during

use. This document does not create any additional obligation for YHI Power and does not constitute additional

Table of Contents

Need help?

Do you have a question about the SL Series and is the answer not in the manual?

Questions and answers

Summary of Contents for YHi SL Series

Page 1 Neuton Power 12.8V LiFePO4 (LFP) Slimline (SL) Series Battery User Manual DOCUMENT NOTICE: The information contained in this manual is the property of YHI Power and is subject to change without notice. It is the customer's responsibility to satisfy itself as to whether the information contained herein is adequate and sufficient for a user's particular use.
Page 2: Table Of Contents
Contents Introduction --------------------------------------------------------------------------------------------------------------------------------- 3 Overview ------------------------------------------------------------------------------------------------------------------------------------- 3 Dimension ----------------------------------------------------------------------------------------------------------------------------------- 3 Specification --------------------------------------------------------------------------------------------------------------------------------- 4 Features -------------------------------------------------------------------------------------------------------------------------------------- 4 Installation Guide -------------------------------------------------------------------------------------------------------------------------- 5 Preparation ------------------------------------------------------------------------------------------------------------------------------- 5 Compatibilities -------------------------------------------------------------------------------------------------------------------------- 5 Installation Tools ------------------------------------------------------------------------------------------------------------------------ 6 Charging Batteries before Use------------------------------------------------------------------------------------------------------- 6 NPL (SL) Battery Terminal ------------------------------------------------------------------------------------------------------------ 7 Storage, Safety and Limitations -------------------------------------------------------------------------------------------------------- 8 Disengaging the Protection ---------------------------------------------------------------------------------------------------------- 8 Controller Settings---------------------------------------------------------------------------------------------------------------------- 9...
Page 3: Introduction
Introduction Neuton Power 12.8V LiFePO4 (LFP) Slimline (SL) series are ultra-thin LiFePO4 solutions, which are specially designed for UTE, 4WD and marine applications. Constructed with high-quality prismatic cells, these batteries were made for better consistency and reliability. The BMS built into the battery system gives it added protection, which is responsible for collecting and analyzing the voltage, temperature and current of each cell.
Page 4: Specification
Specification Model NPL12-100SL NPL12-200SL Rated Voltage 12.8V 12.8V Rated Capacity 100Ah 200Ah Rated Energy 1.28KWh 2.56KWh Maximum Charge Current 100A 200A Recommended Charge Current <50A <100A Maximum Discharge Current 200A 200A Recommended Discharge Cut-off Voltage 11.2V 11.2V Over Discharge Protection Voltage 8.4V –...
Page 5: Installation Guide
Installation Guide Preparation Before installation, please read through all safety information provided in this document. If you have any questions about operation and safe use of the battery system, please contact technical support. Before Operation: • Work must be carried out by qualified personnel who have completed the required training and are certified to undertake electrical work in their state.
Page 6: Installation Tools
Installation Tools Torque Wrench Phillip Screwdriver Insulating gloves Multimeter Charging Batteries before Use Before connecting the batteries in a matrix, the following steps are necessary to reduce the voltage difference between batteries and thereby optimising its performance. 1. Fully charge your batteries separately. 2.
Page 7: Npl (Sl) Battery Terminal
NPL (SL) Battery Terminal NPL (SL) series have two terminals for Anderson 175A blue plugs (as shown below). Note: Anderson cables not included with the purchase of the battery Only use the same plug model type together (Blue Anderson 175A). The Anderson plugs will only insert in one orientation.
Page 8: Storage, Safety And Limitations
Storage, Safety and Limitations • Charging current must be less than the maximum charging current specified in the data sheet. • Charging current exceeding the recommended current may damage the battery. • The discharge current must be less than the maximum discharge current specified in the data sheet.
Page 9: Controller Settings
2. Press the function button again to display the State of Charge (SOC). 3. On the third press, the display screen will turn off. Contact Us YHI Power Pty Ltd Address: 20 - 22 Venture Way, Braeside, VIC 3195 Telephone: 1300 722 028 Email: inquiry@yhipower.com.au...

This manual is also suitable for:

Npl12-100sl Npl12-200sl
