- Page 1 VERSION A0 Door & Window Sensor User Manual...
- Page 2 The Door & Window Sensor works intelligently with Renogy ONE to communicate with other devices. The other devices should support Zigbee 3.0 protocol. Detailed information is in accordance with the final product. Operation Instruction Download DC Home app. Pull out the battery insulation sheet...
- Page 3 Add Door & Window Sensor to Renogy ONE. Prior to adding Door & Window Sensor to Renogy ONE, make sure that Renogy ONE has been bound to DC Home app. For details, see the User Manual of Renogy ONE. Renogy ONE...
-
Page 4: Specifications
Specifications Model SNZB-04 Battery model CR2032 (3V) Wireless Zigbee (IEEE 802.15.4) connection Quiescent current < 2 µA Emission current < 15 mA Installation gap < 10 mm (0.39 in) Operating -10°C-40°C (14°F-104°F) temperature Working humidity 10-90%RH (non-condensing) Material 47 x 27 x 13.5 mm Transmitter: (1.85 x 1.06 x 0.53 in) - Page 5 Controller RBT12400LFPL-... RCC60RVRU Cancel Confirm Device Scene Community Power on Renogy ONE, set the sensor to pairing mode. Choose Renogy ONE on DC Home app, tap "+ > Add Device". Tap the sensor name to add it to Renogy ONE.
-
Page 6: Installation Methods
Delete Sensor from Renogy ONE To disconnect the sensor from Renogy ONE, long press the reset button on the sensor for 5s until the LED indicator flashes three times successfully. Alternatively, you can long-press the sensor on DC Home app to delete it from Renogy ONE. - Page 7 Align the mark on the magnet with that on the transmitter horizontally. Install the transmitter and magnet in the opening and closing sides of the door or window separately. <10mm Make sure the gap between the magnet and the transmitter is less than 10 mm when the door or the window is closed.
-
Page 8: Fcc Warning
Application Door Window NOTE ● Do NOT install the Door & Window Sensor outside the door/window. ● Do NOT install the Door & Window Sensor in a unstable position or in a place exposed to rain or moisture. ● Do NOT install the Door & Window Sensor near wiring or magnetic objects. - Page 9 FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
- Page 10 User Manual. Renogy is not responsible or liable for the failures, damages, or injuries resulting from repair attempted by unqualified personnel or improper installation and operation.
- Page 11 Save 105 gallons of water from being consumed Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
- Page 12 find relevant documentation or get more support via "Contact Us". Renogy reserves the right to change the contents of this manual without notice. Join the Renogy Power Plus Community by downloading the DC Home App. Find your e-warranty here, and more.
