Summary of Contents for CRWSR E-Mobility SL E-mobility
- Page 1 A MARITIME STATEMENT...
- Page 2 Congratulations for having chosen this electric scooter with its unique quality features! Below we have summarized the essential topics regarding the assembly and the use of your e-scooter so that you can use it without any further delay and enjoy it for a long time. Please read these instructions carefully before you use the e-scooter the first time.
- Page 3 ESSENTIAL INFORMATION FIRST CRWSR E-Mobility SL cannot take any responsibility for damages arising from an inadequate maintenance, handling or use. This having been said, the manufacturer’s design must in no case at all be modified (add-on parts or tuning kits, for example).
- Page 4 ESSENTIAL INFORMATION FIRST Take care that clothes or even parts of your body can never get entangled in the wheels. You should always abide by the legal provisions specific to each country (examples: driver’s minimum age, authorized top speed, etc.). We recommend you to wear a helmet while driving.
- Page 5 UNPACKING YOUR CRWSR Once the unpacking is completed, check your CRWSR and first of all ensure that no component is missing, and no damage occurred during the transport. Remove all protection plastic sheets. We recommend you to keep and store the transport protection packaging in case the e-scooter should be returned or dispatched.
- Page 6 ESSENTIAL COMPONENTS AND DISPLAY SCREEN OF YOUR CRWSR 1. Front brake 2. Rear brake 3. Left blinker 4. Right blinker 5. Control unit 6. Speedometer 6. Display screen Entering the code 7. Accelerator and blinker buttons Total mileage 8. Headlight 9.a Snap hook Failure / Malfunction 9.b Folding hook...
- Page 7 ASSEMBLING YOUR CRWSR Unlock the folding hook/buckle on the rear Completely insert the steering T-bar into While using the Allen key, tighten the socket mudguard and knock over the head tube upwards. the head tube. head screws in the corresponding screw holes Push up the blocking latch flat to the tube until it (on both sides).
- Page 8 RECHARGING YOUR CRWSR Please fully recharge your CRWSR before using it for the first time. Lift the rubber cap covering and protecting the charging port placed underneath the wooden deck. Your CRWSR is factory-equipped with a quick and efficient charger to be used in the whole world in addition with a commonly available adapter.
- Page 9 STEERING FUNCTIONS OF YOUR CRWSR BLINKERS COMMAND L/R ACCELERATOR BUTTON « + » BUTTON « - » ON/OFF POWER BUTTON...
- Page 10 STEERING FUNCTIONS OF YOUR CRWSR Power ON/OFF: Hold down the ON/OFF power button for 3 seconds to switch the CRWSR on or off. Turning the lights on and off: Hold down the the “+” button for 3 seconds to turn the lights on or off.
- Page 11 STEERING FUNCTIONS OF YOUR CRWSR Entering a customized code: It is recommendable to modify the code after the initial use. In order to enter you own code, simultaneously hold down both buttons “ON/OFF” and “-” for 10 seconds. A blinking “0” will then be shown.
- Page 12 STEERING FUNCTIONS OF YOUR CRWSR Activating/Deactivating the cruise control mode: Your CRWSR comes with a cruise control! As soon as you are maintaining the accelerator in a constant position for 8 seconds while driving, the cruise control will automatically switch on, which will be signalised by a single beep.
- Page 13 FOLDING AND UNFOLDING YOUR CRWSR Folding your CRWSR: Pull the locking latch forwards and tilt the steering front tube backwards. Push the locking carabiner of the front tube inwards and hook it on the buckle located on the rear mudguard. This being done, you now can easily grip the CRWSR by the front tube to lift and carry it.
- Page 14 TIPS AND TRICKS HOW TO USE YOUR CRWSR Set one foot on the wooden deck and use the other foot to strongly push off your CRWSR. At the same time, push down the accelerator so that the e-scooter can gain momentum. Pull on the brake levers to slow down the CRWSR.
- Page 15 TIPS AND TRICKS HOW TO USE YOUR CRWSR Conditions to be filled by the driver: The driver should possess the physical, sensorial and mental aptitudes required to join in the road traffic. In the case of underage drivers, judging their ability to use an e-scooter is solely incumbent on their legal representatives.
- Page 16 MAINTENANCE AND REPAIR OF YOUR CRWSR Brakes adjustment: Should the brake levers be too hard, please use the 3 mm Allen key to loosen the screw on the brake unit. Gently pull the brake cable line out of the eyelet until the gap between the braking pads and the braking disk is widening.
- Page 17 MAINTENANCE AND REPAIR OF YOUR CRWSR Should the brake levers be too loose, proceed the other way round and push the brake cable line through the eyelet. As a result, the gap between the pads and the braking disk will be narrowing. In this case as well, tighten the socket head screw again and check the braking power, as afore mentioned.
- Page 18 MAINTENANCE AND REPAIR OF YOUR CRWSR Tyres/Air pressure: If you notice a loss of the tyre air pressure, connect the pump adapter to the tyre valve and inflate the tyre. The recommended air pressure should be 2.5 bar. Cleaning and maintenance: By no means use alcohol, petrol or other corrosive chemical products.
- Page 19 INFORMATION ABOUT THE CRWSR BATTERY Please use exclusively the quick charger delivered by the manufacturer with your CRWSR. Using non original components entails the risk of damaging the electronics or the battery. Be sure that the battery is not exposed to temperatures higher than +40° C (104° F) or lower than -20° C (-4° F). Should it be necessary to replace the battery, please contact our Customer Service Team at the following Internet address: www.CRWSR.com/support.
- Page 20 ABOUT YOUR CRWSR - TECHNICAL SPECIFICATIONS (LBH) 1140 mm x 470 mm x 1249 mm (44.9“ x 18.5“ x 49.2“) 20 - 35 km (12.4 – 21.7 mph), depending on the country of use Range: circa 35 km (21.7 miles) 17,6 kg (38.8 lbs) Maximum payload 120 kg (264.6 lbs) Battery 350 W Maximum : 500 W...
- Page 21 All trademarks, logos, type designations and symbols hello@CRWSR.com are protected by CRWSR E-Mobility SL. The informations contained in the present Instruction Manual correspond to technical specifications validated at the date of publication. Substantial modifications are being taken into account in a new release of the Instruction Manual and, along with non-essential technical modifications in safety terms, are being published on the site...
Need help?
Do you have a question about the E-mobility and is the answer not in the manual?
Questions and answers
I forgot the Code what now ??
To reset the code for the CRWSR E-Mobility SL:
1. Hold down both the “ON/OFF” and “-” buttons simultaneously for 10 seconds.
2. A blinking "0" will appear.
3. Use the “+” button to enter the first digit and press “ON/OFF” to confirm (single beep).
4. Repeat for the next two digits.
5. After entering the third digit, press “ON/OFF” twice to validate the new code (double beep confirms reset).
