- Page 1 ISO 9001 Certified Lead with technology Customer VFD pole Win customers with service display JP-8034 USB OPERATION MANUAL...
- Page 2 Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Jarltech. Every effort has been made to ensure that the information in this manual is accurate. Jarltech is not responsible for printing or clerical errors. Jarltech International Inc. 3F, No. 1, Lane 538, Chung Cheng Road, Hsin Tien, Taipei, Taiwan, R.O.C.
- Page 3 1. Introduction 2. Installation 3. Custom Programming Tool Appendix I: Specifications...
- Page 4 Introduction The JP-8034 USB is a 2x20 alphanumeric customer VFD display, Its designed for retail and industrial environments with its outstanding features include high quality vacuum fluorescent display in blue green color, USB interface, easy to use and powerful programming features also compatible with...
-
Page 5: Installation
Installation The JP-8034 USB is compatible to USB 1.1 protocol. Step1. Connects the USB “B” type connector to the JP-8034. Step2. Connects the USB “A” type connector to the PC. - Page 6 500mA current. Then the 8034 can take power via two USB ports for more stable working environment. Step 3: JP-8034 USB driver Installation for Windows Note: Others OS driver please follow the installation notes in the product CD 1.
- Page 7 3. Select the driver in the product CD, please choose the correct diver for your OS version. (For example: WinXP) 4. OS will install the driver, after complete installation please click [Finish]...
- Page 8 Step 4: Check your Simulated COM port After you had installed 8034 USB driver, then hardware will assign an USB simulated COM for 8034 USB. You have to check the USB assigned COM port from “Device Manager” of windows operating system before you starting to programming or using 8034 USB. (The picture shows COM5 as an example), the com port number will depend on your system...
-
Page 9: Programming Commands
There are four programming modes available for 8034 USB which are Jarltech mode, ESC/POS mode, UTC standard and UTC pass through mode. In this chapter we will always use Jarltech mode as an example and command codes. For other modes or multi-character please refer to appendix II.
