Summary of Contents for Scanreco SRC-RCAN
- Page 1 SRC-RCAN transceiver module User & Installation Manual SRC-RCAN transceiver module User & Installation Manual...
- Page 2 SRC-RCAN transceiver module User & Installation Manual Table of Contents Introduction ............................. 3 SRC-RCAN transceiver module ......................3 Terminal connection ........................4 Radio specification .......................... 5 Antenna specification ........................5 Installation ............................5 Regulatory information ........................7 FCC Information ........................7 Industry Canada Information ....................
- Page 3 User & Installation Manual 1. Introduction This module is intended to be installed in a Control unit system as a transceiver by Scanreco AB and it is designed preferably for wireless control of crane installations, travelling hoist units, chain and rope hoists, transfer carriages and similar applications.
- Page 4 SRC-RCAN transceiver module User & Installation Manual 3. Terminal connection Connector Signal Description (CAN) Ground CAN LOW CAN-bus signal CAN low No function (Resting position for optional shield) CAN HIGH CAN-bus signal CAN high No function (Resting position for optional CAN V+)
- Page 5 SRC-RCAN transceiver module User & Installation Manual Connector Signal Description (Mains) Power neural supply 48VAC – 230VAC (50/60Hz) Neural Protective Earth Power line supply 48VAC – 230VAC (50/60Hz) Line 4. Radio specification Attribute Information Frequency 2405-2480 MHz Channels Channels FHSS...
- Page 6 Screw Torx 3,0x8mm Zinc Plated Instruction Place the membrane (Pos 2) in the Host bottom part (Pos 1) acc. to figure 1. Mount the SRC-RCAN module (Pos 2) with 6 screws (Pos 4). Torque = 0.7 Nm. Figure 1 Figure 2...
- Page 7 SRC-RCAN transceiver module User & Installation Manual 7. Regulatory information 7.1 FCC Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 8 SRC-RCAN transceiver module User & Installation Manual une distance de séparation d'au moins 20 cm de toutes les personnes et ne doivent pas être colocalisées ou en fonctionnement en conjonction avec toute autre antenne ou émetteur. Revision history Release Date: YYYY-MM-DD...
