Summary of Contents for Phoenix HARMONY DUSTER
- Page 1 HD11 HARMONY DUSTER Operating and Service Manual © 2014 Phoenix Mixer India Pvt. Ltd. Ver.Phoenix1.1 _ 15-10-2018 - 1 - Phoenix Mixer India Pvt. Ltd.
- Page 2 / or examples are purely coincidental and serve only to clarify the use of the Phoenix Duster. Phoenix shall not be liable for technical or editorial errors or omissions made herein; nor for incidental or consequential damages resulting from the performance or use of this material.
-
Page 3: Table Of Contents
INDEX INTRODUCTION………..………………………..………….………… TECHNICAL SPECIFICATIONS……………………………….……. SAFETY PRECAUTIONS………………………………….………….. MACHINE INSTALLATION..……………………………………….. STARTING UP AND USING MACHINE………………………… SERVICE AND MAINTETANCE……………………………………. WARRANTY AND DISCLAIMER………………………………….. Ver.Phoenix1.1 _ 15-10-2018 - 3 - Phoenix Mixer India Pvt. Ltd. -
Page 4: Introduction
This handbook should be kept in a safe place Narration of the Machine and Technical Specifications The Harmony Duster HD11 is used for the distribution of powders or pre- mixed powders with Sulphur on the crops. One can control the flow of dust coming out of the tank by means of an adjustable lever attached at the bottom of the tank. -
Page 5: Technical Specifications
Z6 1''3/8 with maximum PTO speed of 540 Universal Joint rpm. Power absorption About 5/6 Cv Weight (Kg) 46 Kg Width with fans 1050 mm Height (mm) 1070 mm Depth (mm) 500 mm Ver.Phoenix1.1 _ 15-10-2018 - 5 - Phoenix Mixer India Pvt. Ltd. -
Page 6: Safety Precautions
In the event of smoke being detected in the fan area shut – off the dust flow control lever and immediately disengage the power take –off (PTO) and then take necessary actions. Ver.Phoenix1.1 _ 15-10-2018 - 6 - Phoenix Mixer India Pvt. Ltd. -
Page 7: Machine Installation
Where there are lateral locking mechanisms, fix them in place with the lever facing upwards, between the crankcase ventilator and the diffusers. Ver.Phoenix1.1 _ 15-10-2018 - 7 - Phoenix Mixer India Pvt. Ltd. -
Page 8: Starting Up And Using Machine
Adjust the machine so that it is in the center of the tractor lifter and sufficiently fixed; adjust the third point so that the duster assumes an almost vertical position. Ver.Phoenix1.1 _ 15-10-2018 - 8 - Phoenix Mixer India Pvt. Ltd. - Page 9 Sulphur dust is biological product. During use or when filling the tank it is up to the operator whether to use protective overalls, gloves, goggles or a protective helmet. Ver.Phoenix1.1 _ 15-10-2018 - 9 - Phoenix Mixer India Pvt. Ltd.
- Page 10 500 worked hours (Quantity Lt 0.3 for HD 11 series). Every 200 hours check the degree of viscosity and purity oil with outside temperatures of 40 degree centigrade and more, one advises to use synthetic oil. Ver.Phoenix1.1 _ 15-10-2018 - 10 - Phoenix Mixer India Pvt. Ltd.
-
Page 11: Service And Maintetance
The manufacturer accepts no liability whatsoever for any eventual damage to persons, animals or objects caused by an improper use of the duster or by the operator in a manner different to that indicated in the current leaflet Ver.Phoenix1.1 _ 15-10-2018 - 11 - Phoenix Mixer India Pvt. Ltd. - Page 12 THANK YOU Phoenix Mixer India Pvt. Ltd. Plot No 7, Collage Road, Vadkun, Dahanu Road - 401602 Dist: Palghar, Maharashtra. INDIA Phone: + 91-2528 221120 www.phoenixmixer.com An ISO 9001:2015 Certified Company Ver.Phoenix1.1 _ 15-10-2018 - 12 - Phoenix Mixer India Pvt. Ltd.
