- Page 1 HALO – FVP Frame - Assembly Manual V1.1 Assembly Manual Micro FVP Frame Designs, Images and Content Copyright © Aeroxcraft Ltd. 2012 – 2016 Page 1...
-
Page 2: Notes
HALO – FVP Frame - Assembly Manual V1.1 Notes It is the owner’s responsibility to ensure this model is assembled and fitted out correctly and safely. Ensure that your model is capable of safely and reliably lifting the payload you are asking it to. -
Page 3: Table Of Contents
HALO – FVP Frame - Assembly Manual V1.1 Document Contents Page No Notes ..................... 2 Contact details ................2 Document Contents ............... 3 Package Contents ................. 4 Introduction ................... 6 Step 1 - Assemble Flight Components .......... 7 Step 2 - Assemble Upper Structure ..........8 Step 3 - Attach Upper Structure ............ -
Page 4: Package Contents
HALO – FVP Frame - Assembly Manual V1.1 Package Contents Carbon and G10 parts Qty Item Part No Carbon Hoop Main Plate Camera Supports Antenna Protector Aluminium Parts Qty Item Part No Spacer Blocks Hoop Supports Camera Mount Designs, Images and Content Copyright © Aeroxcraft Ltd. 2012 – 2016... - Page 5 HALO – FVP Frame - Assembly Manual V1.1 Hardware Bag Qty Item M2 x 4 Socket Screws M2 x 3 Socket Screws (For mounting Motors) M2 x 5 CSK Pozi Screws M2.5 x 20 CSK Pozi Screws M2.5 Nuts 1.6mm Spacers 3.2mm Spacers...
-
Page 6: Introduction
HALO – FVP Frame - Assembly Manual V1.1 Introduction This is a basic assembly manual for the construction of the AXC Halo. It does not explain how to connect and setup the Flight controller, ESC, Motors, VTX, RX etc. We are working on more detailed assembly instruction that we will release soon. -
Page 7: Step 1 - Assemble Flight Components
HALO – FVP Frame - Assembly Manual V1.1 Step 1 - Assemble Flight Components Assemble and setup all the flight components at this stage. Cut wires to length and solder in place. Make sure all the wiring is clear of the propellers. -
Page 8: Step 2 - Assemble Upper Structure
HALO – FVP Frame - Assembly Manual V1.1 Step 2 - Assemble the Upper Structure (4x) Carbon Hoops (4x) Spacer Blocks (4x) Hoop Supports (2x) Camera Supports (12x) M2 x 4 Socket Cap Screws (8x) M2 x 5mm CSK (Countersunk) Pozi Screws Assemble the parts as per the diagram below. -
Page 9: Step 3 - Attach Upper Structure
HALO – FVP Frame - Assembly Manual V1.1 Step 3 – Attach Upper Structure (8x) M2 x 4mm Socket Cap Screws Attach the upper structure to the Main Plate with the 8 screws. Designs, Images and Content Copyright © Aeroxcraft Ltd. 2012 – 2016... -
Page 10: Step 4 - Attach Camera
HALO – FVP Frame - Assembly Manual V1.1 Step 4 – Attach Camera The camera attaches to the rear of the aluminium camera mount with the pre- attached self-adhesive foam tape. Make sure that no electrical parts of the camera can touch the aluminium to avoid electrical short out. -
Page 11: Step 5 - Attach Battery Straps
HALO – FVP Frame - Assembly Manual V1.1 Step 5 – Attach Battery Straps (1x) Velcro Strap (2x) Washers (1x) 100mm x Self-Adhesive Velcro (Hook) (1x) 100mm x Self-Adhesive Velcro (Loop) Cut the strap to suit your battery. The strap has holes in each end through which you can screw to the Main Plate as in the photos below. -
Page 12: Step 6 - Attach Props & Fly
HALO – FVP Frame - Assembly Manual V1.1 Step 6 – Attach Props & Fly! Once you are happy with your build attach the props and fly! FLY SAFE! Designs, Images and Content Copyright © Aeroxcraft Ltd. 2012 – 2016... -
Page 13: Flight Controller Setup
HALO – FVP Frame - Assembly Manual V1.1 Flight Controller Setup We use Betaflight on the PIKO flight controller for our own Halos. This is just our preference and you can also use the supplied Cleanflight. You will need to configure your PIKO flight controller to compensate for it being mounted 45 degrees in yaw.
