- Page 1 QUICK USER MANUAL RASHA PROFESSIONAL A/S Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 2 Discard any older versions of Revision this manual and replace with this version. Go to www. rashaprofessional.com for the latest version. Author Date Editor Date Robert Becerra 2/13/17 Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 3: Table Of Contents
1. Operate light ....... 5 Contact us ......... 31 2. Parameter value setting ....6 3. Parameter setting ....... 6 4. Sub Menu (Parameter) ....7 Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 4: Claims
A unique value to be entered or selected in a menu Symbols Meaning Symbols The term “DMX” used throughout this manual refers to the DMX512 digital data transmission protocol Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 5: Safety Notes
Outdoor Use Auto-Ranging Power Supply Sound-Activated Replaceable Fuse User-Serviceable Master/Slave The term “DMX” used throughout this manual refers to the DMX512 digital data transmission protocol Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 6 Kryos™ available in a shiny mirror-finish chrome version, adding glamour to sets while making lights a less invasive presence. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 7 OVERVIEW Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 8 If you are not familiar with or need more information about DMX standards, Master/Slave connectivity, or the DMX cables needed to link this product to a DMX controller, download the DMX Handbook from the Rasha website: www.rashaprofessional.com Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com...
- Page 9 Make sure the clamps are capable of supporting the weight of this product. Use at least 1 mounting point per product. In addition, use a safety cable to link the product to the structure. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com...
-
Page 10: Installation And Attention
• Color wheel: one color wheel, 14 kinds of color chips in one color wheel • Gobo: 17 gobos • Effect Wheel: Rotation eight prism, effect move , frost Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com... -
Page 11: Cable Connection (Dmx)
DMX512 3 Pin 1. Screen 2. – Signal 3. +Signal DMX512 DMX512 5 Pin 1. Screen 2. – Signal 3. +Signal Figure DMX Cable connection Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 12: Rigging (Optional)
Terminal of the accessory is designed for clamps. • Make sure pan/tilt lock unlocked or not. Keep the distance more than 1M from equipment to flammable material or lighting source. Figure Installation Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 13: Chapter 2 3. Panel Operation
When the selected item is value need to been modified, the dialog shown in Figure will popup. 1. Quick Adjust 2. Mirror 3. Apply Value* 4. Adjust Value 5. Save Quit apply Dialog of value setting Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 14: Parameter Setting
• ADDRESS: Set light DMX address. • WORKMOD: Set light work mode, master or slave mode when in auto run mode. • DISPLAY: Set display parameter, eg. select language. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com... -
Page 15: Parameter Instruction
DMX Mode: The light receive data from the DMX controller. AUTO RUN: The light will run with Preset code (data), Note* this will ignore data from the DMX controller. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com... -
Page 16: Set Display
(Do not enter this item unless instructed by RASAH Professional) Address Screen Save Screen Rotate WorkMode Touch Enable Display Touch Rectify Test Advance Status Escape Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 17: Test Light
Tilt Offset: Set TILT original position. Lamp on when: Select lamp on mode: 1. Power on 2. After reset done 3. Manual. Factory setting: restore all parameter to factory setting. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 18: View Status
DMX... Address WorkMode Version A2. 12 Y. 0 Display Elapse 000 H 00M Test total 00022 H 00M Advance Status DMXCLR SysRst Escape Advance Menu Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 19 172-177 (slow to quick) Gobo 4 Shake 178-183 (slow to quick) Gobo 5 Shake 184-189 (slow to quick) Gobo 6 Shake 190-295 (slow to quick) Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 20 Rose / Pink 72-77 Pink 78-83 Pink / Yellow 84-89 Yellow 90-95 Yellow / Light red 96-101 Light red 102-107 Light red / blue 108-113 Blue Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 21 77-127 Pan/ Tilt reset 128-255 Completely reset 0-25 No function Lamp 26-100 Lamp On 101-255 Lamp Off empty Gobo speed Color speed Focus speed Auto Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 22: Pan/Tilt
See below for details. Channel DMX value Description 0-255 Pan fine 0-255 Tilt 0-255 Tilt fine 0-255 Pan/Tilt speed 0-255 Speed adjustment Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 23: Gobo
(slow to quick) Gobo6 Shake 190-295 (slow to quick) Gobo7 Shake 296-201 (slow to quick) Gobo8 Shake 202-207 (slow to quick) Gobo9 Shake 208-213 (slow to quick) Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 24 Gobo13 Shake Gobo 232-237 (slow to quick) Gobo14 Shake 238-243 (slow to quick) Gobo15 Shake 244-249 (slow to quick) Gobo16 Shake 250-255 (slow to quick) Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 25: Color
Light yellow / dark blue 156-161 Dark blue 162-167 Dark blue / white 168-173 Color 29 174-179 Color 30 180-182 Stop Color rainbow effect from 183-255 slow to fast Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 26: Prism
The Fixture it has a built-in mechanical zoom system from 0-4, user can control the zoom from controller as shown below. Channel DMX value Description 0-255 Focus Focus/Zoom 128~255 Insert prism Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... -
Page 27: Strobe/Flash
DMX value Description 0-25 No function Reset 26-76 Reset 77-127 Pan/ Tilt reset 128-255 Completely reset 0-25 No function Lamp 26-100 Lamp On 101-255 Lamp Off Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 28 If channel model is selected “extended”, then the channel shown in Table as shown below Channel DMX value Description empty Gobo speed 0-255 Color speed 0-255 Focus speed 0-255 Auto 0-255 Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 29 Kryos 7R beam, White color box P/N 816231 Firmware update Serial upload via DMX link Kryos 7R beam, Road case P/N 816232 CONSTRUCTION Color(s) Black/White Housing UV-resistant fiber-reinforced composite/Thermoplastic Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
-
Page 30: Returns
Double-boxing is recommended. Rasha reserves the right to use its own discretion to repair or replace returned product(s). Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com... -
Page 31: Contact Us
Voice: +1 (615) 942-6927 Outside the U.S.contact the dealer of record. Follow their instructions to request support or to return a product. Visit our website for contact details. Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com... - Page 32 NOTES Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
- Page 33 Rasha Professional A/S 1130 Palmyrita Ave. Ste 320, Riverside CA, 92507 951-654-3585 rashaprofessional .com info@rashaprofessional.com...
