Page 1: Operation Manual
WINDOW TYPE ROOM AIR CONDITIONER OPERATION MANUAL HW-18C03/R1 Please read this operation manual before using the air conditioner. Please keep it attentively. No.0010546097... -
Page 2: Table Of Contents
Contents Contents ... 2 Part Names ... 3 Operation Guide ... 4-5 Maintenance ... 6 Cautions ... 7 Trouble shooting ... 8 Installation Instructions ... Installation Guide ... 10... -
Page 3: Part Names
Parts Name Machine body Operation panel Ventilation lever Thermostat switch Air inlet (outdoor side) Front panel Air outlet (indoor side) Operation panel Air inlet (indoor side) Cabinet Auto swing switch Mode selection switch... -
Page 4: Operation Guide
Hint When the mode selection switch is turned to " the air conditioner will only blow out air without cooling. If the mode selection switch is turned from cooling mode to fan mode, do not turn it back until at least 3 minutes have elapsed. - Page 5 Otherwise, the fuse may blow due to overload. Do not exceed the selection range. This switch controls the preset indoor temperature to make the air conditioner start or stop automatically, so as to reduce power consumption and operate the system both comfortably and economically.
-
Page 6: Maintenance
(2) Push the part marked " PUSH " until you hear a click. CAUTION Power cord: Only to use an exclusive power cord. Changing installation site: If the air conditioner needs to be changed to another location, please contact the dealer that sold you the unit. Air inlet... -
Page 7: Cautions
For longer and trouble-free operation of the unit, pay special attention to the following: Install the air conditioner at a location strong enough to support the unit. Leave enough space around the air inlet and outlet for better circulation. Avoid sites where flammable gas leaks. -
Page 8: Troubleshooting
Troubleshooting Condition Is plug firmly inserted? Is fuse burned out? Doesn't Is there power failure? operate Is thermostat switch incorrectly adjusted? Is there direct sunlight into the room? Is mode selection switch set to fan mode? No cool air or Are doors or windows left poor cooling open? -
Page 9: Installation Instructions
3. The wiring method should comply with local wiring standards. 4. After installation, the power plug should be easy to access. 5. The breaker of the air conditioner should be an all-pole switch (25A) and the distance between its two contacts should be no less than 3mm. -
Page 10: Installation Guide
3. Remove the air conditioner from its packing carton. 4. Place the air conditioner on the metal support. 5. Stuff gaps in the wall or window with soft sponge material or rubber gaskets to block outside noise and keep cool air from escaping.
