Summary of Contents for Thor’s Drone World DJI RC PRO PLUS
- Page 1 Tripod bracket for DJI RC PRO PLUS by Thor’s Drone World User’s Manual...
- Page 3 Content: A. Tripod bracket B. Pre-Installed Quick Release bracket C. 2x Hex Keys D. 4 x Replacement screws (M2.5 x8) E. Mounting screws for quick release (female) plate* if needed...
- Page 4 Pre-Installed Quick Release bracket Your Tripod bracket for DJI RC PRO PLUS comes with a pre-installed quick release bracket for it to be installed on any Tripod device / StrapThor® - body tripod or similar devices. Press the red button to release the female plate and mount it to your tripod.
-
Page 5: How To Mount
How to mount: Remove the screws from the small brackets located at the rear of the base mount with the smallest hex key provided. - Page 6 Align the controller support stand with the LifThor RC PRO PLUS mount, as shown. The back plate has indentations to provide a secure grip to the stand.
- Page 7 Screw the small brackets back in place. We recommend placing all four screws before tightening them for an even grip...
- Page 8 Now, your Tripod bracket for DJI RC PRO PLUS is properly installed. To access the DJI RC PRO PLUS battery bay there is no need to unmount it. The LifThor mount is cleverly designed for you to fold backwards the controller to access the batteries as shown in the pictures.
- Page 10 www.lifthor.com...
