- Page 1 Owner’s Manual 11' Deluxe Square Offset Umbrella with Umbrella Base Model Number: UMB-11-DLX SKU Number: 101644193 Additional product information: https://shadenshelters.com/11-square-solar-umbrella 1 of 11...
-
Page 2: Parts List
Parts List 11' Deluxe Square Offset Umbrella Letter Illustration Description Qty. Letter Illustration Description Qty. Main Support Post with Base Plate Umbrella Canopy Base Plate Solar Panel Swivel Plate Umbrella Cap Lower Umbrella M8 x 15mm Bolt Support Post Swivel Plate M8 x 20mm Bolt Cover-Bottom Swivel Plate... - Page 3 Assembly Instructions 11' Deluxe Square Offset Umbrella Important: ⚫ Read all the instructions before assembly. Failure to do so may result in faulty assembly and potential injury. Before beginning to assemble the product, remove all protective materials, hardware kit(s), and ⚫...
- Page 4 Step 2: Remove caps from the side of all Poly Bases (G & H) and fill completely with Sand or Water. Secure the caps on all bases. See Figure 2. Note: Poly Bases must be completely filled with sand or water before proceeding to the next step.
- Page 5 Step 4: Remove the Locking Nut from the Lower Umbrella Support Post (D) and attach the Bottom Swivel Plate Cover (E) and Top Swivel Plate Cover (F). See Figure 4. Note: The Locking Nut is reattached in Step 6. Locking Nut Figure 4 Step 5: Place Umbrella Cap (K) on top of Umbrella Canopy and insert the Solar Panel Plug through the...
- Page 6 Step 6: Insert the Main Support Post with Umbrella Canopy (I) into the Lower Umbrella Support Post (D). Attach and Tighten Locking Nut to secure the Lower Umbrella Support (D) to the Main Support Post with Umbrella Canopy (I). See Figure 6. Locking Nut Figure 6 6 of 11...
- Page 7 OPERATING INSTRUCTIONS Step 7: RAISING AND LOWERING UMBRELLA CANOPY. Once assembled loosen the Umbrella Fabric before raising. Press and hold the Lower Handle on the Main Support Post and push to raise the Umbrella Canopy. The Umbrella Canopy height is adjustable and must be secured into one of the pre-drilled hole locking positions on the Main Support Post.
- Page 8 Step 8: OPENING UMBRELLA CANOPY Once the Umbrella Canopy is at the desired height, open the Canopy by turning the Umbrella Crank (P) in the clockwise position. To close the Umbrella Canopy, turn the Umbrella Crank (P) in the counter clockwise position. Note: The Umbrella Canopy must be in the closed position prior to raising or lowering the height.
- Page 9 Step 9: ROTATING UMBRELLA CANOPY Depress and hold the pedal on the Swivel Plate (C) with your foot while turning the Main Support Post (I) to the desired locking position. The Main Support Post (I) can rotate 360 degrees. See Figure 9.
- Page 10 Step 11: SECURING UMBRELLA Close and lower the Umbrella Canopy. Lock into the lowest position. Tie strap around post to secure. See Figure 11-1 and Figure 11-2. Figure 11-1 Figure 11-2 10 of 11...
-
Page 11: Care And Maintenance
Care & Maintenance Maintain your umbrella by storing out of the elements when not in use. Frame: Clean frames with a mild soap and warm water. Do not use abrasive materials, cleaners or bleach. Rinse with clean water and dry thoroughly. Always clean, drain and dry thoroughly before storing for the winter.
